Schneider Conext XW 865-1020-02 Installation Kit

The Schneider Electric RNW865102002 is an essential installation kit designed for the Conext XW Power Distribution Panel. This kit streamlines the installation process by providing all necessary components, ensuring compatibility with the XW+ inverter/charger and enhancing overall system performance. With high-quality materials and an intuitive design, it simplifies integration and saves valuable time during setup.

Product Features

Comprehensive Installation Components

The RNW865102002 installation kit comes equipped with a variety of essential parts, including the XW+ Conduit Box and AC Sync cables. This ensures that users have everything needed for a successful installation, making the process straightforward and user-friendly.

High-Quality Wiring & Connectors

Featuring #6 AWG AC wiring, along with durable #4/0 AWG Arctic Ultraflex battery cables, this kit prioritizes reliability. The factory-installed and labeled wires simplify connectivity, ensuring users can set up their systems with confidence.

Flexible Installation Options

The kit allows for versatile installation configurations. With multiple conduit knockout entry points and a wall mount bracket, users can adapt the setup to their specific environments, facilitating efficient and tailored installations.

Compatibility with XW+ Systems

Engineered to work seamlessly with Schneider Electric's Conext XW+ inverter/charger models, this installation kit supports various configurations. This compatibility ensures that users can effectively expand their systems as needed.

Enhanced Safety Features

The installation kit includes effective safety components designed to minimize risks during setup. By ensuring correct installation processes, users can operate their systems confidently and safely.

How It Works

The RNW865102002 installation kit is designed to integrate with the Conext XW Power Distribution Panel, providing all necessary elements for establishing reliable connections between the distribution panel and inverter/charger. This product simplifies the electrical connections for solar power applications, enhancing usability for both novice and experienced technicians alike.

Wiring Overview

Each kit includes factory-labeled wiring that connects efficiently with various components to ensure optimal performance. This organization eliminates confusion during setup and ensures dependable electricity flow.

Component Compatibility

The parts contained within this kit have been carefully selected to guarantee compatibility with a range of Schneider Electric products. This ensures users have a cohesive and well-functioning system upon installation.

Safety and Compliance

Designed to meet strict safety standards, the RNW865102002 installation kit allows for reliable connections while complying with electrical codes. Users can conduct their setup with peace of mind regarding safety regulations.

Specifications

Product Number	RNW865102002
Product Dimensions (H x W x D)	22.9 x 40.6 x 21.0 cm (8.5 x 16.0 x 8.3 in)
Shipping Dimensions (H x W x D)	44.5 x 33.3 x 30.5 cm (17.5 x 13.0 x 12.0 in)
Shipping Weight	10.5 kg (23.1 lb)
Included Components	XW+ Conduit Box, AC Sync Cables, #6 AWG AC Wiring
Breaker Compatibility	Supports multiple AC breakers
Color	Blue
Wire Gauge	#4/0 AWG Battery Cables
Field Reversibility	Yes
Manufacturer	Schneider Electric
