In Stock
Fronius Symo 480 Inverter - 15.0-3
Fronius Symo 480 Inverter - 15.0-3
Couldn't load pickup availability
Specification
- SKU:PES-SPS-SIV-0321
- Brands: Fronius
-
Compliance special features:
- Rapid Shutdown Ready
- Height: 28.5
- Length: 8.9
-
Special sections quote cta:
- AFCI
- Width: 20.1
Product Description
-
Fronius Symo 15.0-3 Inverter for Efficient Solar Installations
The Fronius 15.0-3 inverter is a robust solution for solar energy systems, designed to optimize performance and efficiency. Highlighting advanced features like rapid shutdown compliance and DC reverse polarity protection, this inverter ensures safe and effective energy conversion.
Product Features
DC Reverse Polarity Protection
The Fronius 15.0-3 inverter includes DC reverse polarity protection, ensuring safe operation and preventing potential damage, especially valuable in dynamic environments.
Anti-Islanding Compliance
Equipped with anti-islanding protection, this inverter adheres to UL 1741-2010 and IEEE 1547-2003 standards, enhancing reliability during grid disturbances.
Over Temperature Protection
To safeguard operations, the device offers over temperature protection through output power derating and active cooling, maintaining efficiency even in challenging conditions.
Arc Fault Circuit Interruption (AFCI)
With AFCI technology, the Fronius 15.0-3 inverter provides an additional layer of safety by detecting potentially dangerous arc faults.
Rapid Shutdown Compliant
Fully compliant with rapid shutdown requirements, this inverter supports stringent safety protocols for solar installations.
How It Works
Discover how the Fronius 15.0-3 inverter harmonizes multiple components to deliver stable and efficient solar power conversion, catering to both technical and general users.
Cooling System
The variable speed fan cooling system regulates the internal temperature, optimizing performance and extending the unit's lifespan.
Transformerless Technology
Its transformerless design reduces weight and increases energy efficiency, delivering enhanced performance in solar power management.
Smart Interface Options
Equipped with USB, RS422 ports, and integrated with the Fronius Datamanager 2.0, the inverter supports data logging and remote monitoring.
Specifications
Maximum Output Power 14995 VA Output Configuration 480 V Delta +N** Frequency Range 45-65 Hz Nominal Operating Frequency 60 Hz Efficiency 98.0% Max, 97.5% CEC Protection Class NEMA 4X Installation Indoor and outdoor, tilt 0 - 90 degrees* Ambient Temperature Range -40F to + 140F Permitted Humidity 0 - 100% (non-condensing) Weight 95.7 lbs -
