Unirac Roofmount End Clamp 30-40MM - 310820

Unirac Roofmount End Clamp 30-40MM - 310820

The Unirac Roofmount End Clamp 30-40MM is designed to streamline the installation of solar mounting systems. This product, identified by the model number 310820, emphasizes simplicity and efficiency with its robust design, offering excellent durability and ease of assembly for framed photovoltaic (PV) modules. With this solution, users can ensure a sturdy mounting while enjoying significant time savings during installation.

Product Features

Simple Component Structure

The Unirac 310820 features a straightforward design consisting of only two main components€”a fully assembled ballast bay and a universal module clip. This simplicity allows for quick assembly, meaning less pre-installation effort and greater efficiency on the job site.

Innovative Bonding Mechanism

Equipped with a chemical locking hex bolt, this end clamp provides a reliable UL2703 certified grounding path from the module to the ballast bay. Users will appreciate how easy it is to establish a secure connection with just a simple turn of a wrench, enhancing both safety and reliability.

Accessory Compatibility

The Unirac Roofmount is designed to be accessory-rich, easily integrating with off-the-shelf wire management products. This flexibility enables users to customize their installations according to specific project needs, ensuring optimal performance and aesthetics.

Low-Cost Roof Protection Option

A membrane-friendly rubber roof pad is available as an additional low-cost option, effectively offering protection for roof surfaces. This feature not only helps maintain the integrity of roofing materials but also supports overall installation longevity.

Extensive Distribution Network

Unirac boasts the largest network of stocking distributors, assuring prompt delivery and excellent customer support. The availability of the Unirac 310820 ensures that users can depend on timely service, making it an ideal choice for both residential and commercial installations.

How It Works

The operation of the Unirac Roofmount End Clamp is designed to be intuitive and efficient for users of all skill levels. By understanding its core components and their interactions, users can quickly set up a reliable solar mounting system that meets industry standards.

Ballast Bay Function

The fully assembled ballast bay serves as the foundation of the mounting system, providing stability and resistance against environmental forces. Its solid construction ensures that solar modules remain securely in place, even under adverse conditions.

Universal Module Clip Role

The universal module clip is integral in holding solar panels firmly in position, creating a seamless connection with the ballast bay. Its design is compatible with various module types, making it versatile for different installation scenarios.

Grounding Bolt Inclusion

This component's innovative grounding bolt ensures electrical safety and compliance with UL2703 standards, greatly enhancing the reliability of the entire system. This meticulous attention to safety strengthens user confidence in the installation.

Specifications
