The Growatt SYN 200-XH-US-11A is the 200A whole-home automatic transfer switch for MIN TL-XH-US V3 inverters, with integrated SM-US smart meter and sub-0.5s switchover.
Key Features
- 200A automatic transfer switch for whole-home backup (<0.5s switchover)
- Integrated SM-US smart meter
- Built-in split-phase transformer for 120/240V output; NEMA 4X outdoor rated
- Remote wake-up and control; 10-year warranty
- For generator port, see SYN 200-XH-US-13A
Compatibility: Growatt MIN TL-XH-US V3 inverters (whole home backup); ARO/APX & LG Prime/Enblock batteries
Specifications
| Model | SYN 200-XH-US-11A |
| Part Number | PV06.0005500 |
| Rating | 200A, 120/240V split-phase |
| Switchover | <0.5 s on/off-grid |
| Smart Meter | Integrated SM-US |
| Generator Port | No (see 13A) |
| Enclosure | NEMA 4X |
| Certifications | UL1741, CSA 22.2 No.107.1, UL869A, FCC Part 15 |
Authorized Growatt distribution — full manufacturer warranty. Ships as single units via ground from Growatt USA (Eastvale, CA) or Louisville, KY.
