Type Monocrystalline Model No. SE5-78HBD 630W Product Warranty 30 Years Power Warranty 10 Years of 90 %, 25 Years of 84.7 % Total Degradation Rate ⏳ 0.61 % Power Tolerance 0 ~ +0.8 % Maximum Power (Pmax) 630 Wp Voltage at Maximum Power (Vmpp) 47.7 V Current at Maximum Power (Impp) 13.21 A Open Circuit Voltage (Voc) 57.08 V Short Circuit Current (Isc) 13.86 A Panel Efficiency 22.54 % Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.30 %/°C Temperature Coefficient of Voc -0.25 %/°C Temperature Coefficient of Isc +0.046 %/°C Maximum System Voltage 1500 V Series Fuse Rating 25 A Panel Dimension (H/W/D) 2465x1134x35 mm Weight 30 kg Cell Size 182×182 mm Cell Number 156 Glass Type Tempered Glass Thickness 3.2 mm Encapsulant Type EVA Back Cover Type TPT Frame Type Anodized Aluminium Junction Box Diodes 3 Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Cable Length 300 mm Download Manufacturer's PDF Datasheet
Technology: Bifacial, TOPCon
Power Range: 615 ~ 635 Wp
Panel Efficiency: 22 ~ 22.72 %
Weight: 30 kg
Seller Name: SunEvo Solar Co., Ltd.
Country: China
| SKU | PES-SPS-SOL-18862 |
|---|---|
| Manufacturer | PES Global |
| Container price | |
| Container qty | |
| Odoo id | |
| Pallet price | |
| Pallet qty | |
| Unit price | |
| Manufacturer | |
| Model number | |
| Wattage |
No documents available for this product. Contact us to request documentation.
