Solis 10kW Inverter with SunSpec Transmitter - Model 1P10K-4G-US-SPRT
The Solis 1P10K-4G-US-SPRT is a powerful inverter designed for efficient solar power conversion. Featuring advanced MPPT technology, this inverter maximizes energy harvest from your solar panels. With a peak efficiency of 97.8%, it offers reliable performance for both residential and commercial installations. The built-in SunSpec Transmitter ensures compliance with rapid shutdown requirements, enhancing both safety and functionality.
Product Features
Advanced MPPT Technology
The Solis inverter features multi-point maximum power tracking technology, improving energy yield under varied conditions and ensuring optimal performance.
High Efficiency
Achieve an outstanding 97.8% maximum efficiency, reducing energy loss and boosting overall power output for your solar setup.
SunSpec Rapid Shutdown Transmitter
This built-in feature meets necessary safety standards, ensuring the rapid shutdown of your system, protecting both property and personnel.
Optional Connectivity
The inverter supports optional cellular and Wi-Fi connections, enabling easy monitoring and remote system management.
Durable and Compliant Design
Designed with TYPE 4X ingress protection, this inverter operates in harsh weather conditions and complies with multiple regulatory standards for safety and performance.
How It Works
The Solis 1P10K-4G-US-SPRT operates by converting DC power from solar panels into AC power suitable for home or grid usage. Its advanced MPPT system tracks power outputs, optimizing for efficiency and ensuring maximum energy conversion.
DC to AC Conversion
Utilizing robust transformerless technology, this inverter efficiently converts solar energy into usable electricity, minimizing waste and loss.
Grid Compatibility
The inverter seamlessly integrates with standard grid systems, automatically syncing to offer stable and consistent energy supply to your household or business.
Peak Efficiency Performance
With a high CEC efficiency rating of 97.5%, the inverter ensures that maximum power from your solar panels is utilized, contributing to greater energy savings and sustainability.
Specifications
| Model Name | Solis-1P10K-4G-US-SPRT |
| Max Input Voltage | 600 V |
| Rated Output Power | 10 kW |
| Max Efficiency | 97.8% |
| Operating Temperature Range | -13°F to 140°F (-25°C to 60°C) |
| Ingress Protection | TYPE 4X |
| Communication Options | RS485, Optional: Cellular, Wi-Fi |
| Weight | 45.6 lbs (20.7 kgs) |
| Dimensions | 13.1 x 28.8 x 9.8 in (333 x 732 x 249 mm) |
| Compliance | UL 1741, IEEE 1547, FCC |
Specifications & Documents: Full specifications & datasheet for Solis 10kW 4-MPPT Inverter With SunSpec Transmitter - 1P10K-4G-US-SPRT
| SKU | PES-SPS-SIV-0528 |
|---|---|
| MPN | 1P10K-4G-US-SPRT |
| Manufacturer | Solis |
| Brands | |
| Compliance special features | |
| Container price | |
| Container qty | |
| Documents | |
| Height | |
| Isfollow | |
| Isindex | |
| Length | |
| Pallet price | |
| Unit price | |
| Width | |
| Manufacturer |
No documents available for this product. Contact us to request documentation.
