• ACS Enerji LXR-MHCB-144C-535W
1 1
Manufacturer IronRidge
OEM Authorized BABA Compliant Full Warranty 7-10 Business Days Delivery
In Stock
SKU: PES-SPS-SOL-0233Brand: IronRidge

In Stock

ACS Enerji LXR-MHCB-144C-535W

ACS Enerji LXR-MHCB-144C-535W

$107.00 USD
$107.00 USD
Sale Sold out
Shipping calculated at checkout.
Delivery: 7-10 business days. Freight calculated at checkout based on destination & weight.
Return policy

Specification

  • SKU:PES-SPS-SOL-0233
  • Brand: IronRidge
  • Container price: $57,780.00 USD
  • Container qty: 720
  • Mpn: LXR-MHCB-144C
  • Odoo id: 26,650
  • Pallet price: $2,728.50 USD
  • Pallet qty: 30
  • Unit price: $107.00 USD
  • Manufacturer: IronRidge
  • Wattage: 535
View full details
7-10 business days delivery from Louisville, KY
Orders ship via freight or ground from our Louisville, KY warehouse. Tracking provided once your order ships.
IronRidge

PES Supply is an authorized distributor for IronRidge. 50,000+ SKUs from 169 authorized brands.

Type Monocrystalline Model No. LXR-MHCB-144C-535W Product Warranty 10 Years Power Tolerance 0 ~ +1 % Maximum Power (Pmax) 535 Wp Voltage at Maximum Power (Vmpp) 41.5 V Current at Maximum Power (Impp) 12.89 A Open Circuit Voltage (Voc) 49.8 V Short Circuit Current (Isc) 13.6 A Panel Efficiency 20.7 % Temperature 45±3 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.29 %/°C Temperature Coefficient of Voc -0.25 %/°C Temperature Coefficient of Isc 0.045 %/°C Maximum System Voltage 1500 V Series Fuse Rating 25 A Panel Dimension (H/W/D) 2278x1134x35 mm Weight 28 kg Cell Number 144 Glass Type Tempered Glass Thickness 3.2 mm Frame Type Anodized Aluminium Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Download Manufacturer's PDF Datasheet

Technology: Bifacial, PERC
Power Range: 525 ~ 550 Wp
Panel Efficiency: 20.31 ~ 21.28 %
Weight: 28 kg
Seller Name: ACS Enerji (Lexron)
Country: Turkey

SKUPES-SPS-SOL-0233
ManufacturerIronRidge
BrandIronRidge
Container price$57,780.00 USD
Container qty720
MpnLXR-MHCB-144C
Odoo id26,650
Pallet price$2,728.50 USD
Pallet qty30
Unit price$107.00 USD
ManufacturerIronRidge
Wattage535

    No documents available for this product. Contact us to request documentation.

    ACS Enerji LXR-MHCB-144C-535W $107.00

    You May Also Need

    Outback Power FX/GS Replacement Inverter Fan Kit - FX/GS FAN KIT

    Outback Power FX/GS Replacement Inverter Fan Kit - FX/GS FAN KIT

    $34.19
    Magnum 2.8KW Battery-based Inverter - MS2812-L

    Magnum 2.8KW Battery-based Inverter - MS2812-L

    $1,925.02
    EG4 Electronics Chargeverter - GC 48V 100A 5120W Output 240/120V Input Battery Charger

    EG4 Electronics Chargeverter - GC 48V 100A 5120W Output 240/120V Input Battery Charger

    $729.92
    Outback Power Control Board - SPARE-105

    Outback Power Control Board - SPARE-105

    $276.45
    Tesla Multi Powerwall Stacking Kit - 1112154-00-B

    Tesla Multi Powerwall Stacking Kit - 1112154-00-B

    $424.23
    Tigo TS4-A-O 1500V UL/TUV 1.2M Cable MC4 700W Max Power - 461-00252-32

    Tigo TS4-A-O 1500V UL/TUV 1.2M Cable MC4 700W Max Power - 461-00252-32

    $43.17
    Outback Power System Display and Controller - MATE3s

    Outback Power System Display and Controller - MATE3s

    $572.07
    APSystems 4-Module Micro Inverter For 375W+ Modules - QS1

    APSystems 4-Module Micro Inverter For 375W+ Modules - QS1

    $336.00

    Specifications

    Power Rating 535W

    Product Description

    • Type Monocrystalline Model No. LXR-MHCB-144C-535W Product Warranty 10 Years Power Tolerance 0 ~ +1 % Maximum Power (Pmax) 535 Wp Voltage at Maximum Power (Vmpp) 41.5 V Current at Maximum Power (Impp) 12.89 A Open Circuit Voltage (Voc) 49.8 V Short Circuit Current (Isc) 13.6 A Panel Efficiency 20.7 % Temperature 45±3 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.29 %/°C Temperature Coefficient of Voc -0.25 %/°C Temperature Coefficient of Isc 0.045 %/°C Maximum System Voltage 1500 V Series Fuse Rating 25 A Panel Dimension (H/W/D) 2278x1134x35 mm Weight 28 kg Cell Number 144 Glass Type Tempered Glass Thickness 3.2 mm Frame Type Anodized Aluminium Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Download Manufacturer's PDF Datasheet

      Technology: Bifacial, PERC
      Power Range: 525 ~ 550 Wp
      Panel Efficiency: 20.31 ~ 21.28 %
      Weight: 28 kg
      Seller Name: ACS Enerji (Lexron)
      Country: Turkey
