    In Stock

    ACS Enerji LXR-MHC-120C-385W

    ACS Enerji LXR-MHC-120C-385W

    $77.00 USD
    $77.00 USD
    Sale Sold out
    Shipping calculated at checkout.
    Return policy

    Specification

    • SKU:PES-SPS-SOL-0215
    • Brand: IronRidge
    • Container price: $41,580.00 USD
    • Container qty: 720
    • Mpn: LXR-MHC-120C
    • Odoo id: 18,520
    • Pallet price: $1,963.50 USD
    View full details

    Product Description

    • Type Monocrystalline Model No. LXR-MHC-120C-385W Product Warranty 10 Years Power Tolerance 0 ~ +1.5 % Maximum Power (Pmax) 385 Wp Voltage at Maximum Power (Vmpp) 35.15 V Current at Maximum Power (Impp) 10.95 A Open Circuit Voltage (Voc) 42.18 V Short Circuit Current (Isc) 11.55 A Panel Efficiency 21.1 % Temperature 45±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.36 %/°C Temperature Coefficient of Voc -0.304 %/°C Temperature Coefficient of Isc 0.05 %/°C Maximum System Voltage 1500 V Series Fuse Rating 20 A Panel Dimension (H/W/D) 1756x1039x35 mm Weight 20 kg Cell Number 120 Glass Type Tempered Glass Thickness 3.2 mm Frame Type Anodized Aluminium Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Download Manufacturer's PDF Datasheet

      Technology: PERC
      Power Range: 375 ~ 400 Wp
      Panel Efficiency: 20.55 ~ 21.92 %
      Weight: 20 kg
      Seller Name: ACS Enerji (Lexron)
      Country: Turkey
