    ACS Enerji LXR-MHC-144C-435W

    ACS Enerji LXR-MHC-144C-435W

    $87.00 USD
    $87.00 USD
    Sale Sold out
    Shipping calculated at checkout.
    Return policy

    Specification

    • SKU:PES-SPS-SOL-0219
    • Brand: IronRidge
    • Competitor price comparison: {"pes_price":87.0,"avg_competitor_price":173.99,"min_competitor_price":173.99,"max_competitor_price":173.99,"diff_pct":100.0,"competitor_count":1,"checked_at":"2026-07-21"}
    • Container price: $46,980.00 USD
    • Container qty: 720
    • Mpn: LXR-MHC-144C
    • Odoo id: 18,064
    View full details

    Product Description

    • Type Monocrystalline Model No. LXR-MHC-144C-435W Product Warranty 10 Years Power Tolerance 0 ~ +1 % Maximum Power (Pmax) 435 Wp Voltage at Maximum Power (Vmpp) 40.8 V Current at Maximum Power (Impp) 10.66 A Open Circuit Voltage (Voc) 48.96 V Short Circuit Current (Isc) 11.25 A Panel Efficiency 19.97 % Temperature 45±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.35 %/°C Temperature Coefficient of Voc -0.27 %/°C Temperature Coefficient of Isc 0.048 %/°C Maximum System Voltage 1500 V Series Fuse Rating 20 A Panel Dimension (H/W/D) 2096x1039x35 mm Weight 24 kg Cell Number 144 Glass Type Tempered Glass Thickness 3.2 mm Frame Type Anodized Aluminium Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Download Manufacturer's PDF Datasheet

      Technology: PERC
      Power Range: 435 ~ 460 Wp
      Panel Efficiency: 19.97 ~ 21.12 %
      Weight: 24 kg
      Seller Name: ACS Enerji (Lexron)
      Country: Turkey
