    ACS Enerji LXR-MHC-72C-230W

    ACS Enerji LXR-MHC-72C-230W

    $46.00 USD
    $46.00 USD
    Sale Sold out
    Shipping calculated at checkout.
    Return policy

    Specification

    • SKU:PES-PA-ELC-24944
    • Brand: IronRidge
    • Container price: $24,840.00 USD
    • Container qty: 720
    • Mpn: LXR-MHC-72C
    • Odoo id: 27,806
    • Pallet price: $1,173.00 USD
    View full details

    Product Description

    • Type Monocrystalline Model No. LXR-MHC-72C-230W Product Warranty 10 Years Power Tolerance 0 ~ +2.5 % Maximum Power (Pmax) 230 Wp Voltage at Maximum Power (Vmpp) 21.15 V Current at Maximum Power (Impp) 10.87 A Open Circuit Voltage (Voc) 25.38 V Short Circuit Current (Isc) 11.47 A Panel Efficiency 20.32 % Temperature 45±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.36 %/°C Temperature Coefficient of Voc -0.304 %/°C Temperature Coefficient of Isc 0.05 %/°C Maximum System Voltage 1000 V Series Fuse Rating 15 A Panel Dimension (H/W/D) 1581x716x30 mm Weight 13 kg Cell Number 72 Glass Type Tempered Glass Thickness 3.2 mm Frame Type Anodized Aluminium Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Download Manufacturer's PDF Datasheet

      Technology: PERC
      Power Range: 225 ~ 230 Wp
      Panel Efficiency: 19.88 ~ 20.32 %
      Weight: 13 kg
      Seller Name: ACS Enerji (Lexron)
      Country: Turkey
