    ACS Enerji LXR-MHCB-144C-525W

    ACS Enerji LXR-MHCB-144C-525W

    $105.00 USD
    $105.00 USD
    Sale Sold out
    Shipping calculated at checkout.
    Return policy

    Specification

    • SKU:PES-SPS-SOL-0231
    • Brand: IronRidge
    • Container price: $56,700.00 USD
    • Container qty: 720
    • Mpn: LXR-MHCB-144C
    • Odoo id: 26,648
    • Pallet price: $2,677.50 USD
    View full details

    Product Description

    • Type Monocrystalline Model No. LXR-MHCB-144C-525W Product Warranty 10 Years Power Tolerance 0 ~ +1 % Maximum Power (Pmax) 525 Wp Voltage at Maximum Power (Vmpp) 41.3 V Current at Maximum Power (Impp) 12.71 A Open Circuit Voltage (Voc) 49.56 V Short Circuit Current (Isc) 13.41 A Panel Efficiency 20.31 % Temperature 45±3 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.29 %/°C Temperature Coefficient of Voc -0.25 %/°C Temperature Coefficient of Isc 0.045 %/°C Maximum System Voltage 1500 V Series Fuse Rating 25 A Panel Dimension (H/W/D) 2278x1134x35 mm Weight 28 kg Cell Number 144 Glass Type Tempered Glass Thickness 3.2 mm Frame Type Anodized Aluminium Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Download Manufacturer's PDF Datasheet

      Technology: Bifacial, PERC
      Power Range: 525 ~ 550 Wp
      Panel Efficiency: 20.31 ~ 21.28 %
      Weight: 28 kg
      Seller Name: ACS Enerji (Lexron)
      Country: Turkey
