    AmoSolar AS450M6-144

    AmoSolar AS450M6-144

    $5.00 USD
    $5.00 USD
    Sale Sold out
    Shipping calculated at checkout.
    Return policy

    Specification

    • SKU:PES-SPS-SOL-1180
    • Container price: $37.80 USD
    • Container qty: 720
    • Pallet price: $1.78 USD
    • Pallet qty: 30
    • Unit price: $0.07 USD
    View full details

    Product Description

    • Type Monocrystalline Model No. AS450M6-144 Product Warranty 12 Years Power Warranty 10 Years of 93.05 %, 25 Years of 84.8 % Total Degradation Rate ⏳ 0.61 % Maximum Power (Pmax) 450 Wp Voltage at Maximum Power (Vmpp) 41.52 V Current at Maximum Power (Impp) 10.84 A Open Circuit Voltage (Voc) 49.7 V Short Circuit Current (Isc) 11.36 A Panel Efficiency 20.58 % Maximum Power (Pmax) 340 Wp Voltage at Maximum Power (Vmpp) 39.19 V Current at Maximum Power (Impp) 8.68 A Open Circuit Voltage (Voc) 46.9 V Short Circuit Current (Isc) 9.25 A Temperature 45±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.35 %/°C Temperature Coefficient of Voc -0.272 %/°C Temperature Coefficient of Isc 0.044 %/°C Maximum System Voltage 1500 V Series Fuse Rating 20 A Panel Dimension (H/W/D) 2094x1038x35 mm Weight 23 kg Cell Number 144 Junction Box Diodes 3 Junction Box Protection Class IP 67 Connector Type MC4 Cable Crossection 4 mm2 Cable Length 300 mm Download Manufacturer's PDF Data

      Technology: PERC
      Power Range: 440 ~ 465 Wp
      Panel Efficiency: 20.13 ~ 21.27 %
      Weight: 23 kg
      Seller Name: AmoSolar Co., Ltd.
      Country: China
