AmoSolar AS500M10-132
PayPal Pay in 4 interest-free payments of $20.00 on qualifying orders, or monthly financing with PayPal Pay Later.
Available at checkout for eligible US buyers. Subject to approval.
Ships by freight. Carrier checkout rates can’t price this correctly — we quote the exact delivered rate to your ZIP.
Orders ship via freight or ground from our Louisville, KY warehouse. Tracking provided once your order ships.
Ships via LTL freight — palletized, liftgate available. Our team confirms freight details within 1 business day.
Secure checkout · Wire/ACH accepted on quotes · Freight arranged for you
Transit estimates from Louisville, KY. Freight details →
- SKU
- PES-SPS-SOL-1194
Complete the job
Compatible gear contractors pair with this item
PES Supply is an authorized distributor for ENF Solar. 50,000+ SKUs from 169 authorized brands.
Type Monocrystalline Model No. AS500M10-132 Product Warranty 12 Years Power Warranty 10 Years of 93.05 %, 25 Years of 84.8 % Total Degradation Rate ⏳ 0.61 % Maximum Power (Pmax) 500 Wp Voltage at Maximum Power (Vmpp) 38.7 V Current at Maximum Power (Impp) 12.93 A Open Circuit Voltage (Voc) 47.86 V Short Circuit Current (Isc) 13.39 A Panel Efficiency 21.06 % Maximum Power (Pmax) 376.7 Wp Voltage at Maximum Power (Vmpp) 35.34 V Current at Maximum Power (Impp) 10.66 A Open Circuit Voltage (Voc) 42.73 V Short Circuit Current (Isc) 11.24 A Temperature 45±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.35 %/°C Temperature Coefficient of Voc -0.275 %/°C Temperature Coefficient of Isc 0.045 %/°C Maximum System Voltage 1500 V Series Fuse Rating 25 A Panel Dimension (H/W/D) 2094x1134x35 mm Weight 24.5 kg Cell Number 132 Junction Box Diodes 3 Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Cable Length 300 mm Download Manufacturer's
Power Range: 485 ~ 515 Wp
Panel Efficiency: 20.42 ~ 21.69 %
Weight: 24.5 kg
Seller Name: AmoSolar Co., Ltd.
Country: China
| SKU | PES-SPS-SOL-1194 |
|---|---|
| Manufacturer | ENF Solar |
| Container price | |
| Container qty | |
| Pallet price | |
| Pallet qty | |
| Unit price | |
| Manufacturer | |
| Model number |
No documents available for this product. Contact us to request documentation.
