General Electric 9.6kW Split-Phase Hybrid Inverter

Explore the innovative General Electric GEH7.6-1U-US10, a high-capacity split-phase hybrid inverter tailored for versatility and reliability. With support for up to four Maximum Power Point Trackers (MPPTs) and compatibility with high voltage batteries ranging from 80 to 495V, this inverter is designed to optimize energy generation and consumption efficiently. Its robust power capacity, between 5 kW and 9.6 kW, ensures a reliable and continuous power supply for various applications.

Product Features

Advanced MPPT Technology

The GEH7.6-1U-US10 features up to four MPPTs, allowing for enhanced solar energy harnessing even in varied conditions, maximizing electricity generation through precision management of solar inputs.

Compatibility with High Voltage Batteries

Support for a wide battery voltage range of 80 to 495V enables flexible integration with diverse battery systems, enhancing the system's versatility and efficiency in power storage and usage.

Transformerless Design for Maximum Efficiency

Incorporating a transformerless design, this inverter achieves a maximum efficiency of 97.6%, reducing energy losses during conversion and maximizing the overall energy output for users.

Full Backup Capacity

With a full backup capacity of up to 9.6 kW, this model ensures that critical devices continue to operate during grid outages, providing peace of mind with uninterrupted power supply.

Integrated Safety Features

The GEH7.6-1U-US10 includes comprehensive safety mechanisms such as Arc-fault Current Interrupter (AFCI) and rapid shutdown capabilities, ensuring the protection of both photovoltaic systems and connected devices.

How It Works

This inverter efficiently manages energy flow between solar panels, batteries, and the utility grid. It intelligently allocates solar power to immediate usage, battery storage, or grid export, depending on energy needs and production levels.

Solar to Grid Power Management

The inverter precisely adjusts DC inputs via MPPTs to optimize energy conversion and directly feed into the grid or store for later use, based on solar availability.

Battery Integration

Capable of managing high voltage battery systems, it seamlessly charges and discharges stored energy to ensure consistent power availability, aligning with user consumption patterns.

Continuous Monitoring and Safety Compliance

Equipped with monitoring interfaces and integrated protection systems, it actively supervises all operations to comply with safety standards and guarantee reliable performance.
