GoodWe MS G3 US Series PV string Inverter w/ EZLink 4G - GW6000-MS-US30

In Stock

Get yours today!

9+ sold

In the last 7 days

Flat Rate Shipping - Calculated at Checkout

Delivery timeframe shown above at checkout

Lifetime Customer Support

Unlimited lifetime support, always available.

In Stock

SKU PES-SPS-SIV-0681

GoodWe MS G3 US Series PV string Inverter w/ EZLink 4G - GW6000-MS-US30

$1,929.43 USD

$ $1,929.43 USD

Sale Sold out

Quantity

Secure Payment Methods

In Stock

Get yours today!

9+ sold

In the last 7 days

Flat Rate Shipping - Calculated at Checkout

Delivery timeframe shown above at checkout

Lifetime Customer Support

Unlimited lifetime support, always available.

In High Demand! Order Now To Secure Your Items

Request a Free Quote

Technical Details

SKU:PES-SPS-SIV-0681
Documents:
Datasheet
Installation Guide
Manual
Warranty
Mpn number: GW6000-MS-US30-4G
Height:7.8
Width:26.4
Length:19.2

Got Questions? We’re Here to Help!

Our support team is ready to assist you with product guidance, order details, or any questions you might have.

(888) 876-0007

Instant Live Chat

Mon-Fri 10am-6pm EST

View full details

GoodWe MS-US (G3) — GW6000-MS-US30, 6 kW PV String Inverter w/ EZLink 4G

The GoodWe MS G3 US Series PV string Inverter - GW6000 is a high-performance, grid-tied solar inverter designed to deliver reliable energy conversion for modern residential and small commercial solar systems. Built with advanced safety features, intelligent monitoring, and superior efficiency, this inverter is engineered to meet the demanding standards of the U.S. solar market while ensuring long-term performance and stability.

Designed for installers and system owners who prioritize reliability and smart energy management, the GoodWe MS G3 US Series PV string Inverter - GW6000 supports seamless integration with advanced monitoring solutions and delivers consistent output even in challenging grid conditions.

Type 4X (IP66), built-in optimization, AFCI & Rapid Shutdown, EZLink (IEEE 2030.5). Bluetooth commissioning; Wi-Fi/LAN monitoring; 4G connectivity included for this variant.

Technical Specifications — GW6000-MS-US30

PV Input
Max. input power	9,600 W
Max. input voltage	600 Vdc
MPPT voltage @ nominal power (240 V)	198–500 V
MPPT voltage @ nominal power (208 V)	171–500 V
Start-up voltage	80 V
Nominal input voltage (240 V / 208 V)	380 V / 330 V
Max input current / Isc per MPPT	16 A / 23.4 A
MPPT trackers / Strings per MPPT	2 / 1
AC Output
Nominal output power (240 V / 208 V)	6,000 W / 5,200 W
Nominal apparent power (240 V / 208 V)	6,000 VA / 5,200 VA
Max AC active/apparent power (240 V / 208 V)	6,000 W / 5,200 W • 6,000 VA / 5,200 VA
Nominal voltage / frequency	240 / 208 V • 60 Hz
Max output current	25.0 A
Power factor / THD	~1 (0.8 lead…0.8 lag) / < 3%
Efficiency
Max / CEC (240 V / 208 V)	97.5% / 96.5% / 96.0%
Protection & Safety
Integrated	PV string current, insulation & residual current monitoring; reverse-polarity; anti-islanding; AC overcurrent/short-circuit/overvoltage; DC switch; AFCI; Rapid Shutdown
Surge protection	DC SPD Type III (Type II optional); AC SPD Type III (Type II optional)
General
Operating / storage temp	−31~+140 °F (−35~+60 °C), derate ≥ 113 °F / −40~+158 °F
Humidity / altitude	0–95% / 9,842 ft (3,000 m)
Cooling	Natural convection
Interface / comms / protocol	LED, WLAN + App / RS485, Wi-Fi + LAN + Bluetooth, 4G / Modbus-RTU (SunSpec)
Dimensions / Weight	19.2 × 26.4 × 7.8 in • 51.8 lb
Noise / Topology / Night self-use	< 25 dB / Non-isolated / < 5 W
Ingress protection	Type 4X (IP66)
Certifications / Grid Standards
Standards	UL1741 / UL1741SB / UL1741-CRD, UL1699B, CSA C22.2; IEEE 2030.5, IEEE 1547 / 1547.1-2020; California Rule 21; EMC: FCC Part 15 Class B

Variant note — EZLink 4G

4G support is marked optional in the manual; this model listing includes the 4G connectivity with EZLink.

Overview of GoodWe MS G3 US Series PV string Inverter - GW6000

The GoodWe MS G3 US Series PV string Inverter - GW6000 is part of GoodWe’s next-generation inverter lineup, offering enhanced efficiency, intelligent grid support functions, and improved system visibility. With a compact and lightweight design, it enables easy installation while maintaining robust performance across varying load conditions.

This inverter supports high DC input capacity, allowing flexibility in solar panel configuration. Its optimized MPPT technology ensures maximum energy harvest throughout the day, making it an ideal choice for rooftops with partial shading or variable sunlight exposure.

Key Features and Technical Advantages

High Conversion Efficiency

The inverter is designed to deliver excellent conversion efficiency, minimizing energy loss during DC-to-AC conversion. This results in higher usable power output and improved overall system returns.

Advanced Safety Protection

Equipped with multiple protection mechanisms such as AFCI (Arc Fault Circuit Interruption), anti-islanding protection, and ground fault detection, the system ensures safe operation for both users and the grid.

Smart Monitoring with EZLink 4G

The GoodWe MS G3 US Series PV string Inverter w/ EZLink 4G - GW6000-MS-US30) enables real-time system monitoring through wireless connectivity. This allows users to track energy production, system health, and performance data remotely, reducing maintenance time and improving operational transparency.

Installation and Design Flexibility

The GoodWe MS G3 US Series PV string Inverter - GW6000 is engineered with installer convenience in mind. Its compact housing and simplified wiring structure reduce installation time and labor costs. The inverter supports a wide input voltage range, making it compatible with various PV module configurations.

Its fanless or low-noise cooling design enhances durability and ensures stable performance even under continuous operation. This makes it suitable for both indoor and outdoor installations.

Grid Compatibility and Performance Stability

Built to meet stringent U.S. grid interconnection standards, the inverter supports advanced grid functions such as voltage ride-through, frequency ride-through, and reactive power control. These features help maintain grid stability while maximizing solar energy utilization.

The GoodWe MS G3 US Series PV string Inverter - GW6000 adapts dynamically to grid conditions, ensuring uninterrupted power generation and compliance with evolving utility requirements.

Long-Term Reliability and Durability

Constructed using high-quality components, the inverter is designed for long-term operation under diverse environmental conditions. Its robust enclosure protects internal electronics from dust, moisture, and temperature variations, ensuring consistent performance over its lifespan.

With intelligent self-diagnostics and fault detection, potential issues are identified early, helping to minimize downtime and protect system investment.

Why Choose the GoodWe MS G3 US Series PV string Inverter - GW6000?

Choosing this inverter means investing in efficiency, safety, and smart energy control. It is well-suited for homeowners and businesses seeking dependable solar performance with advanced monitoring capabilities.

By integrating modern grid support functions and intelligent communication options, the GoodWe MS G3 US Series PV string Inverter - GW6000 supports future-ready solar installations while delivering dependable energy output today.
