Horay Solar HS590TC-MHO-D
Horay Solar HS590TC-MHO-D
Couldn't load pickup availability
Specification
- SKU:PES-SPS-SOL-8653
- Container price:
- Container qty:
- Pallet price:
- Pallet qty:
- Unit price:
Product Description
-
Type Monocrystalline Model No. HS590TC-MHO-D Product Warranty 15 Years Power Warranty 30 Years of 87.4 % Total Degradation Rate ⏳ 0.42 % Power Tolerance 0 ~ +3 % Maximum Power (Pmax) 590 Wp Voltage at Maximum Power (Vmpp) 43.44 V Current at Maximum Power (Impp) 13.59 A Open Circuit Voltage (Voc) 51.63 V Short Circuit Current (Isc) 14.38 A Panel Efficiency 22.8 % Maximum Power (Pmax) 448 Wp Voltage at Maximum Power (Vmpp) 40.72 V Current at Maximum Power (Impp) 11.01 A Open Circuit Voltage (Voc) 48.94 V Short Circuit Current (Isc) 11.62 A Temperature 45±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.28 %/°C Temperature Coefficient of Voc -0.23 %/°C Temperature Coefficient of Isc 0.04 %/°C Maximum System Voltage 1500 V Series Fuse Rating 25 A Panel Dimension (H/W/D) 2279x1134x30 mm Weight 31.5 kg Cell Number 144 Glass Type Anti-reflection Coating Glass Thickness 2 mm Frame Type Anodized Aluminium, Black Junction Box Diodes 3 Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Cable Length 300 mm Download Manufacturer's PDF Datasheet
Technology: Bifacial, N-type
Power Range: 570 ~ 590 Wp
Panel Efficiency: 22.1 ~ 22.8 %
Weight: 31.5 kg
Seller: Horay Solar Co., Ltd
Country: China -
