Out of Stock
HY SOLAR 495
HY SOLAR 495
Couldn't load pickup availability
Specification
- SKU:PES-SPS-SOL-7846
- Container price:
- Container qty:
- Pallet price:
- Pallet qty:
- Unit price:
Product Description
-
Type Monocrystalline Model No. 495 Product Warranty 15 Years Power Warranty 30 Years of 87.4 % Total Degradation Rate ⏳ 0.42 % Power Tolerance 0 ~ +3 % Maximum Power (Pmax) 495 Wp Voltage at Maximum Power (Vmpp) 36.37 V Current at Maximum Power (Impp) 13.61 A Open Circuit Voltage (Voc) 43.52 V Short Circuit Current (Isc) 14.35 A Panel Efficiency 22.4 % Maximum Power (Pmax) 371.7 Wp Voltage at Maximum Power (Vmpp) 34.13 V Current at Maximum Power (Impp) 10.89 A Open Circuit Voltage (Voc) 41.01 V Short Circuit Current (Isc) 11.51 A Temperature 42±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.29 %/°C Temperature Coefficient of Voc -0.24 %/°C Temperature Coefficient of Isc 0.043 %/°C Maximum System Voltage 1500 V Series Fuse Rating 30 A Panel Dimension (H/W/D) 1952x1134x30 mm Weight 26.5 kg Cell Size 183.75×182.2 mm Cell Number 120 Glass Type Anti-reflection Coating Glass Thickness 2 mm Encapsulant Type EVA Frame Type Anodized Aluminium, Black Junction Box Diodes 3 Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Cable Length 300 mm Download Manufacturer's PDF Datasheet
Technology: Bifacial, TOPCon, N-type
Power Range: 495 ~ 515 Wp
Panel Efficiency: 22.4 ~ 23.3 %
Weight: 26.5 kg
Seller: Hongyuan Green Energy Co., Ltd.
Country: China -
