1 0

    In Stock

    Isola New Energy YH100W-18M

    Isola New Energy YH100W-18M

    $5.00 USD
    $5.00 USD
    Sale Sold out
    Shipping calculated at checkout.
    Return policy

    Specification

    • SKU:PES-SPS-SOL-9200
    • Container price: $75.60 USD
    • Container qty: 720
    • Odoo id: 25,051
    • Pallet price: $3.57 USD
    • Pallet qty: 30
    • Unit price: $0.14 USD
    View full details

    Product Description

    • Type Monocrystalline Model No. YH100W-18M Product Warranty 12 Years Power Warranty 25 Years of 80 % Total Degradation Rate ⏳ 0.8 % Power Tolerance 0 ~ +3 % Maximum Power (Pmax) 100 Wp Voltage at Maximum Power (Vmpp) 17.7 V Current at Maximum Power (Impp) 5.65 A Open Circuit Voltage (Voc) 20.61 V Short Circuit Current (Isc) 5.95 A Panel Efficiency 19.44 % Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.35 %/°C Temperature Coefficient of Voc -0.27 %/°C Temperature Coefficient of Isc 0.048 %/°C Maximum System Voltage 1500 V Series Fuse Rating 20 A Panel Dimension (H/W/D) 770x668x30 mm Weight 5.4 kg Cell Size 210×70 mm Cell Number 30 Glass Type Tempered Glass Thickness 3.2 mm Frame Type Anodized Aluminium Junction Box Protection Class IP 67 Connector Type MC4 Cable Crossection 2.5 mm2 Cable Length 500 mm Download Manufacturer's PDF Datasheet

      Technology: PERC
      Power Range: 100 Wp
      Panel Efficiency: 19.44%
      Weight: 5.4 kg
      Seller Name: Zhejiang Isola New Energy Co., Ltd.
      Country: China
