    Isola New Energy YH150W-18M

    Isola New Energy YH150W-18M

    $5.00 USD
    $5.00 USD
    Sale Sold out
    Shipping calculated at checkout.
    Return policy

    Specification

    • SKU:PES-SPS-SOL-9203
    • Container price: $64.80 USD
    • Container qty: 720
    • Odoo id: 24,546
    • Pallet price: $3.06 USD
    • Pallet qty: 30
    • Unit price: $0.12 USD
    View full details

    Product Description

    • Type Monocrystalline Model No. YH150W-18M Product Warranty 12 Years Power Warranty 10 Years of 90 %, 25 Years of 80 % Total Degradation Rate ⏳ 0.8 % Power Tolerance 0 ~ +3 % Maximum Power (Pmax) 150 Wp Voltage at Maximum Power (Vmpp) 21.06 V Current at Maximum Power (Impp) 7.13 A Open Circuit Voltage (Voc) 24.78 V Short Circuit Current (Isc) 7.5 A Panel Efficiency 19.53 % Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.340 %/°C Temperature Coefficient of Voc -0.250 %/°C Temperature Coefficient of Isc 0.04 %/°C Maximum System Voltage 1500 V Series Fuse Rating 10 A Panel Dimension (H/W/D) 1150x668x30 mm Weight 8.1 kg Cell Size 210×90 mm Cell Number 36 Glass Type Tempered Glass Thickness 3.2 mm Encapsulant Type EVA Back Cover Type TPT Frame Type Anodized Aluminium Junction Box Diodes 2 Junction Box Protection Class IP 65 Connector Type MC4 Cable Crossection 2.5 mm2 Cable Length 500 mm Download Manufacturer's PDF Datasheet

      Power Range: 150 Wp
      Panel Efficiency: 19.53%
      Weight: 8.1 kg
      Seller Name: Zhejiang Isola New Energy Co., Ltd.
      Country: China
