1 0

    In Stock

    Isola New Energy YH190W-19.5M

    Isola New Energy YH190W-19.5M

    $5.00 USD
    $5.00 USD
    Sale Sold out
    Shipping calculated at checkout.
    Return policy

    Specification

    • SKU:PES-SPS-SOL-9206
    • Container price: $59.40 USD
    • Container qty: 720
    • Odoo id: 24,493
    • Pallet price: $2.80 USD
    • Pallet qty: 30
    • Unit price: $0.11 USD
    View full details

    Product Description

    • Type Monocrystalline Model No. YH190W-19.5M Product Warranty 12 Years Power Warranty 10 Years of 90 %, 25 Years of 80 % Total Degradation Rate ⏳ 0.8 % Power Tolerance 0 ~ +3 % Maximum Power (Pmax) 190 Wp Voltage at Maximum Power (Vmpp) 21.86 V Current at Maximum Power (Impp) 8.7 A Open Circuit Voltage (Voc) 25.62 V Short Circuit Current (Isc) 9.19 A Panel Efficiency 19.15 % Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.34 %/°C Temperature Coefficient of Voc -0.25 %/°C Temperature Coefficient of Isc 0.04 %/°C Maximum System Voltage 1500 V Series Fuse Rating 15 A Panel Dimension (H/W/D) 1485x668x30 mm Weight 10.5 kg Cell Size 210×105 mm Cell Number 39 Glass Type Tempered Glass Thickness 3.2 mm Encapsulant Type EVA Back Cover Type TPT Frame Type Aluminium Junction Box Diodes 2 Junction Box Protection Class IP 65 Connector Type MC4 Cable Crossection 2.5 mm2 Cable Length 500 mm Download Manufacturer's PDF Datasheet

      Power Range: 180 ~ 200 Wp
      Panel Efficiency: 18.15 ~ 20.16 %
      Weight: 10.5 kg
      Seller Name: Zhejiang Isola New Energy Co., Ltd.
      Country: China
