Isola New Energy YH200W-19.5M
PayPal Pay in 4 interest-free payments of $25.00 on qualifying orders, or monthly financing with PayPal Pay Later.
Available at checkout for eligible US buyers. Subject to approval.
Ships by freight. Carrier checkout rates can’t price this correctly — we quote the exact delivered rate to your ZIP.
Orders ship via freight or ground from our Louisville, KY warehouse. Tracking provided once your order ships.
Ships via LTL freight — palletized, liftgate available. Our team confirms freight details within 1 business day.
Secure checkout · Wire/ACH accepted on quotes · Freight arranged for you
Transit estimates from Louisville, KY. Freight details →
- SKU
- PES-SPS-SOL-9208
Complete the job
Compatible gear contractors pair with this item
PES Supply is an authorized distributor for PES Global. 50,000+ SKUs from 169 authorized brands.
Type Monocrystalline Model No. YH200W-19.5M Product Warranty 12 Years Power Warranty 10 Years of 90 %, 25 Years of 80 % Total Degradation Rate ⏳ 0.8 % Power Tolerance 0 ~ +3 % Maximum Power (Pmax) 200 Wp Voltage at Maximum Power (Vmpp) 22.45 V Current at Maximum Power (Impp) 8.91 A Open Circuit Voltage (Voc) 26.01 V Short Circuit Current (Isc) 9.41 A Panel Efficiency 20.16 % Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.34 %/°C Temperature Coefficient of Voc -0.25 %/°C Temperature Coefficient of Isc 0.04 %/°C Maximum System Voltage 1500 V Series Fuse Rating 15 A Panel Dimension (H/W/D) 1485x668x30 mm Weight 10.5 kg Cell Size 210×105 mm Cell Number 39 Glass Type Tempered Glass Thickness 3.2 mm Encapsulant Type EVA Back Cover Type TPT Frame Type Aluminium Junction Box Diodes 2 Junction Box Protection Class IP 65 Connector Type MC4 Cable Crossection 2.5 mm2 Cable Length 500 mm Download Manufacturer's PDF Datasheet
Power Range: 180 ~ 200 Wp
Panel Efficiency: 18.15 ~ 20.16 %
Weight: 10.5 kg
Seller Name: Zhejiang Isola New Energy Co., Ltd.
Country: China
| SKU | PES-SPS-SOL-9208 |
|---|---|
| Manufacturer | PES Global |
| Container price | |
| Container qty | |
| Odoo id | |
| Pallet price | |
| Pallet qty | |
| Unit price | |
| Manufacturer | |
| Model number | |
| Wattage |
No documents available for this product. Contact us to request documentation.
