Isola New Energy YH310W-36P
Isola New Energy YH310W-36P
Couldn't load pickup availability
Specification
- SKU:PES-SPS-SOL-9222
- Container price:
- Container qty:
- Odoo id:
- Pallet price:
- Pallet qty:
- Unit price:
Product Description
-
Type Polycrystalline Model No. YH310W-36P Product Warranty 12 Years Power Tolerance 0 ~ +3 % Maximum Power (Pmax) 310 Wp Voltage at Maximum Power (Vmpp) 37.3 V Current at Maximum Power (Impp) 8.31 A Open Circuit Voltage (Voc) 44.43 V Short Circuit Current (Isc) 8.85 A Panel Efficiency 15.98 % Maximum Power (Pmax) 230 Wp Voltage at Maximum Power (Vmpp) 33.26 V Current at Maximum Power (Impp) 6.92 A Open Circuit Voltage (Voc) 39.9 V Short Circuit Current (Isc) 7.47 A Temperature 45±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.4 %/°C Temperature Coefficient of Voc -0.29 %/°C Temperature Coefficient of Isc 0.048 %/°C Maximum System Voltage 1500 V Series Fuse Rating 15 A Panel Dimension (H/W/D) 1956x992x35 mm Weight 20.5 kg Cell Size 156×156 mm Cell Number 72 Glass Type Tempered Glass Thickness 3.2 mm Frame Type Anodized Aluminium Junction Box Protection Class IP 67 Connector Type MC4 Cable Crossection 4 mm2 Cable Length 900 mm Download Manufacturer's PDF
Technology: PERC
Power Range: 300 ~ 330 Wp
Panel Efficiency: 15.46 ~ 17.01 %
Weight: 20.5 kg
Seller Name: Zhejiang Isola New Energy Co., Ltd.
Country: China -
