    Joinsun Solar JAM72S42-645/LR

    Joinsun Solar JAM72S42-645/LR

    $5.00 USD
    $5.00 USD
    Sale Sold out
    Shipping calculated at checkout.
    Return policy

    Specification

    • SKU:PES-SPS-SOL-10638
    • Container price: $48.60 USD
    • Container qty: 720
    • Pallet price: $2.29 USD
    • Pallet qty: 30
    • Unit price: $0.09 USD
    View full details

    Product Description

    • Type Monocrystalline Model No. JAM72S42-645/LR Product Warranty 12 Years Power Warranty 1 Years of 99 %, 25 Years of 89.4 % Total Degradation Rate ⏳ 0.42 % Power Tolerance 0 ~ +3 % Maximum Power (Pmax) 645 Wp Voltage at Maximum Power (Vmpp) 44.49 V Current at Maximum Power (Impp) 14.5 A Open Circuit Voltage (Voc) 53.07 V Short Circuit Current (Isc) 15.36 A Panel Efficiency 23.1 % Maximum Power (Pmax) 488 Wp Voltage at Maximum Power (Vmpp) 42.09 V Current at Maximum Power (Impp) 11.6 A Open Circuit Voltage (Voc) 50.22 V Short Circuit Current (Isc) 12.29 A Temperature 45±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.29 %/°C Temperature Coefficient of Voc -0.25 %/°C Temperature Coefficient of Isc 0.045 %/°C Maximum System Voltage 1500 V Series Fuse Rating 25 A Panel Dimension (H/W/D) 2465x1134x30 mm Weight 29.6 kg Cell Number 144 Glass Thickness 3.2 mm Junction Box Diodes 3 Junction Box Protection Class IP 68 Cable Crossection 4 mm2 Download Manufacturer

      Technology: N-type
      Power Range: 645 Wp
      Panel Efficiency: 23.10%
      Weight: 29.6 kg
      Seller Name: Jiangsu Jujiang New Energy Co., Ltd. (Joinsun Solar)
      Country: China
