JSUN JS18-MH72-560 560W Monocrystalline Solar Panel
Model JS18-MH72-560 | Monocrystalline | 144 Half-Cell | Mono | 1500V System Voltage
Product Overview
The JSUN JS18-MH72-560 is a high-output monocrystalline solar panel designed for dependable performance in demanding projects. It delivers 560 Wp of rated power with 21.7% module efficiency, helping maximize energy generation in limited roof or ground space. The module uses 144 cells and a durable 2279 x 1134 x 35 mm format. With a 1500V maximum system voltage, it suits modern commercial and utility-scale installations. The panel is built with tempered glass, an anodized aluminium frame, and IP68 junction box protection for long-term reliability. Its strong electrical ratings and stable temperature behavior make it a practical choice for efficient solar system design.
Key Benefits
High Power Output: A rated 560 Wp output supports strong performance across commercial and utility projects.
Strong Efficiency: The 21.7% module efficiency helps increase energy yield from the available installation area.
Durable Construction: Tempered glass, anodized aluminium, and IP68 protection improve outdoor reliability.
Stable Electrical Performance: Low temperature coefficients help maintain output during changing weather conditions.
Installation Friendly: MC4 connectors, 4 mm² cables, and a 1500V system rating simplify integration.
How It Works
This solar panel converts sunlight into electricity through monocrystalline silicon cells arranged in a 144-cell layout. The cell design helps capture solar energy efficiently and convert it into usable direct current power. Under standard test conditions, the module reaches 560 Wp with a Vmpp of 42.25 V and an Impp of 13.25 A. That balance supports stable string design and efficient system operation. The half-cell structure also helps reduce internal current and power loss. As a result, the panel can maintain better output in real-world conditions. The durable frame, sealed junction box, and tempered glass protect the module during long-term outdoor use.
Monocrystalline Conversion: Sunlight strikes the monocrystalline cells, which generate direct current for the system. The high-efficiency cell design supports strong energy conversion from each square meter.
Half-Cell Electrical Layout: The 144-cell configuration helps reduce resistance and internal current. This can lower power loss and improve output consistency across the module.
Weather-Ready Protection: The tempered glass, IP68 junction box, and aluminium frame protect critical components. These features support reliable operation in harsh outdoor environments.
Technical Specifications
| Brand | JSUN |
| Model Number | JS18-MH72-560 |
| Product Type | Monocrystalline solar panel |
| Power Range | 555 ~ 575 Wp |
| Maximum Power (Pmax) | 560 Wp |
| Voltage at Maximum Power (Vmpp) | 42.25 V |
| Current at Maximum Power (Impp) | 13.25 A |
| Open Circuit Voltage (Voc) | 49.77 V |
| Short Circuit Current (Isc) | 14.19 A |
| Module Efficiency | 21.7% |
| Temperature (NMOT) | 45±2 °C |
| Operating Temperature Range | -40 to 80 °C |
| Temperature Coefficient of Pmax | -0.35 %/°C |
| Temperature Coefficient of Voc | -0.27 %/°C |
| Temperature Coefficient of Isc | +0.05 %/°C |
| Maximum System Voltage | 1500 V |
| Cell Size | 182 × 182 mm |
| Cell Number | 144 |
| Dimensions | 2279 × 1134 × 35 mm |
| Weight | 27.5 kg |
| Glass Type | Tempered glass |
| Glass Thickness | 3.2 mm |
| Frame Type | Anodized aluminium |
| Junction Box Protection Class | IP68 |
| Connector Type | MC4 |
| Cable Cross Section | 4 mm² |
| Cable Length | 300 mm |
| Seller Name | Jiangsu Jsun New Energy Co., Ltd. |
| Country of Origin | China |
Certifications & Compliance
Certifications: IEC 61215, IEC 61730, ISO 9001, ISO 14001, ISO 45001
Inverter Compatibility: Compatible with standard 1500V solar system designs using MC4 connections
Environmental: Built for -40 to 80 °C operating conditions with IP68-rated junction box protection
Warranty: 15-year product quality and process guarantee, plus 25-year linear power warranty
