MY Solar MY-M10/144-545
MY Solar MY-M10/144-545
Couldn't load pickup availability
Specification
- SKU:PES-SPS-SOL-12107
- Container price:
- Container qty:
- Pallet price:
- Pallet qty:
- Unit price:
Product Description
-
Type Monocrystalline Model No. MY-M10/144-545 Product Warranty 12 Years Power Warranty 12 Years of 90 %, 25 Years of 80.1 % Total Degradation Rate ⏳ 0.8 % Power Tolerance 0 ~ +1 % Maximum Power (Pmax) 545 Wp Voltage at Maximum Power (Vmpp) 40.86 V Current at Maximum Power (Impp) 13.34 A Open Circuit Voltage (Voc) 49.5 V Short Circuit Current (Isc) 14.04 A Panel Efficiency 21.12 % Maximum Power (Pmax) 405.61 Wp Voltage at Maximum Power (Vmpp) 38.02 V Current at Maximum Power (Impp) 10.68 A Open Circuit Voltage (Voc) 46.73 V Short Circuit Current (Isc) 11.37 A Temperature 45±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.37 %/°C Temperature Coefficient of Voc -0.29 %/°C Temperature Coefficient of Isc 0.048 %/°C Maximum System Voltage 1500 V Series Fuse Rating 25 A Panel Dimension (H/W/D) 2278x1133x35 mm Weight 28 kg Cell Size 182×91 mm Cell Number 144 Glass Type Anti-reflection Coating, Tempered Glass Thickness 3.2 mm Encapsulant Type EVA Back Cover Type TPE Frame Type Anodized Aluminium Junction Box Diodes 2 Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Cable Length 350 mm Download Manufacturer's PDF Datasheet
Technology: PERC
Power Range: 530 ~ 560 Wp
Panel Efficiency: 20.54 ~ 21.68 %
Weight: 28 kg
Seller: MY Solar Technology Co., Ltd.
Country: China -
