MY Solar MY-M10/144-560
MY Solar MY-M10/144-560
Couldn't load pickup availability
Specification
- SKU:PES-SPS-SOL-12110
- Container price:
- Container qty:
- Pallet price:
- Pallet qty:
- Unit price:
Product Description
-
Type Monocrystalline Model No. MY-M10/144-560 Product Warranty 12 Years Power Warranty 12 Years of 90 %, 25 Years of 80.1 % Total Degradation Rate ⏳ 0.8 % Power Tolerance 0 ~ +1 % Maximum Power (Pmax) 560 Wp Voltage at Maximum Power (Vmpp) 41.23 V Current at Maximum Power (Impp) 13.58 A Open Circuit Voltage (Voc) 49.9 V Short Circuit Current (Isc) 14.21 A Panel Efficiency 21.68 % Maximum Power (Pmax) 416.77 Wp Voltage at Maximum Power (Vmpp) 38.36 V Current at Maximum Power (Impp) 10.86 A Open Circuit Voltage (Voc) 47.14 V Short Circuit Current (Isc) 11.55 A Temperature 45±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.37 %/°C Temperature Coefficient of Voc -0.29 %/°C Temperature Coefficient of Isc 0.048 %/°C Maximum System Voltage 1500 V Series Fuse Rating 25 A Panel Dimension (H/W/D) 2278x1133x35 mm Weight 28 kg Cell Size 182×91 mm Cell Number 144 Glass Type Anti-reflection Coating, Tempered Glass Thickness 3.2 mm Encapsulant Type EVA Back Cover Type TPE Frame Type Anodized Aluminium Junction Box Diodes 2 Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Cable Length 350 mm Download Manufacturer's PDF Datasheet
Technology: PERC
Power Range: 530 ~ 560 Wp
Panel Efficiency: 20.54 ~ 21.68 %
Weight: 28 kg
Seller: MY Solar Technology Co., Ltd.
Country: China -
