    MY Solar MY-M10/60-440

    MY Solar MY-M10/60-440

    $5.00 USD
    $5.00 USD
    Sale Sold out
    Shipping calculated at checkout.
    Return policy

    Specification

    • SKU:PES-SPS-SOL-12112
    • Container price: $54.00 USD
    • Container qty: 720
    • Pallet price: $2.55 USD
    • Pallet qty: 30
    • Unit price: $0.10 USD
    View full details

    Product Description

    • Type Monocrystalline Model No. MY-M10/60-440 Product Warranty 25 Years Power Tolerance 0 ~ +1 % Maximum Power (Pmax) 440 Wp Voltage at Maximum Power (Vmpp) 34.21 V Current at Maximum Power (Impp) 12.87 A Open Circuit Voltage (Voc) 41.44 V Short Circuit Current (Isc) 13.55 A Panel Efficiency 20.36 % Maximum Power (Pmax) 327.46 Wp Voltage at Maximum Power (Vmpp) 31.83 V Current at Maximum Power (Impp) 10.29 A Open Circuit Voltage (Voc) 39.12 V Short Circuit Current (Isc) 10.94 A Temperature 45±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.37 %/°C Temperature Coefficient of Voc -0.29 %/°C Temperature Coefficient of Isc 0.048 %/°C Maximum System Voltage 1500 V Series Fuse Rating 25 A Panel Dimension (H/W/D) 1908x1133x35 mm Weight 24 kg Cell Number 120 Glass Type Anti-reflection Coating, Tempered Glass Thickness 3.2 mm Encapsulant Type EVA Back Cover Type TPE Frame Type Anodized Aluminium Junction Box Diodes 2 Junction Box Protection Class IP 68 Connector

      Power Range: 435 ~ 455 Wp
      Panel Efficiency: 20.13 ~ 21.05 %
      Weight: 24 kg
      Seller Name: MY Solar Technology Co., Ltd.
      Country: China
