MY Solar MY-M6/144-430
MY Solar MY-M6/144-430
Couldn't load pickup availability
Specification
- SKU:PES-SPS-SOL-12190
- Container price:
- Container qty:
- Pallet price:
- Pallet qty:
- Unit price:
Product Description
-
Type Monocrystalline Model No. MY-M6/144-430 Product Warranty 25 Years Power Tolerance 0 ~ +3 % Maximum Power (Pmax) 430 Wp Voltage at Maximum Power (Vmpp) 40.72 V Current at Maximum Power (Impp) 10.56 A Open Circuit Voltage (Voc) 48.69 V Short Circuit Current (Isc) 11.07 A Panel Efficiency 19.46 % Maximum Power (Pmax) 319.9 Wp Voltage at Maximum Power (Vmpp) 37.9 V Current at Maximum Power (Impp) 8.441 A Open Circuit Voltage (Voc) 45.3 V Short Circuit Current (Isc) 8.948 A Temperature 45±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.39 %/°C Temperature Coefficient of Voc -0.3 %/°C Temperature Coefficient of Isc 0.06 %/°C Maximum System Voltage 1500 V Series Fuse Rating 20 A Panel Dimension (H/W/D) 2108x1048x35 mm Weight 25.6 kg Cell Number 144 Glass Type Anti-reflection Coating, Tempered Glass Thickness 3.2 mm Frame Type Anodized Aluminium Junction Box Protection Class IP 68 Cable Crossection 4 mm2 Cable Length 300 mm Download Manufacturer's PDF Data
Power Range: 430 ~ 455 Wp
Panel Efficiency: 19.46 ~ 20.6 %
Weight: 25.6 kg
Seller Name: MY Solar Technology Co., Ltd.
Country: China -
