    MY Solar MY-M6/144-445

    MY Solar MY-M6/144-445

    $5.00 USD
    $5.00 USD
    Sale Sold out
    Shipping calculated at checkout.
    Return policy

    Specification

    • SKU:PES-SPS-SOL-12193
    • Container price: $54.00 USD
    • Container qty: 720
    • Pallet price: $2.55 USD
    • Pallet qty: 30
    • Unit price: $0.10 USD
    View full details

    Product Description

    • Type Monocrystalline Model No. MY-M6/144-445 Product Warranty 25 Years Power Tolerance 0 ~ +3 % Maximum Power (Pmax) 445 Wp Voltage at Maximum Power (Vmpp) 41.75 V Current at Maximum Power (Impp) 10.66 A Open Circuit Voltage (Voc) 49.55 V Short Circuit Current (Isc) 11.17 A Panel Efficiency 20.14 % Maximum Power (Pmax) 331 Wp Voltage at Maximum Power (Vmpp) 38.8 V Current at Maximum Power (Impp) 8.531 A Open Circuit Voltage (Voc) 46 V Short Circuit Current (Isc) 9.044 A Temperature 45±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.39 %/°C Temperature Coefficient of Voc -0.3 %/°C Temperature Coefficient of Isc 0.06 %/°C Maximum System Voltage 1500 V Series Fuse Rating 20 A Panel Dimension (H/W/D) 2108x1048x35 mm Weight 25.6 kg Cell Number 144 Glass Type Anti-reflection Coating, Tempered Glass Thickness 3.2 mm Frame Type Anodized Aluminium Junction Box Protection Class IP 68 Cable Crossection 4 mm2 Cable Length 300 mm Download Manufacturer's PDF Datashee

      Power Range: 430 ~ 455 Wp
      Panel Efficiency: 19.46 ~ 20.6 %
      Weight: 25.6 kg
      Seller Name: MY Solar Technology Co., Ltd.
      Country: China
