Pattern New Energy 205

Trusted by 1,000s of Contractors & Installers

Ships Direct from Manufacturer — typically leaves the dock in 3–7 business days

SKU PES-SPS-SOL-14071

OEM Authorized Dealer Full OEM Warranty

$180.00 USD

~~$0.01~~ $180.00 USD

Sold out

Quantity

Sold by the pallet (10) — PowerLink & trade: request 10+

Sold by the pallet (10) PowerLink Network & trade customers can request 10+ →

Buying 5+ pallets or a truckload?Get a Volume Quote →

Offloading overstock or decommissioned gear? We buy surplus equipment →

Secure checkout · Wire/ACH accepted on quotes · Freight arranged for you

Ships via LTL freight — palletized, liftgate available. Our team confirms freight details within 1 business day.

SKU: PES-SPS-SOL-14071

Complete the job

Compatible gear contractors pair with this item

Microinverter APsystems QT2 1.7kW 3-Ph Microinverter 124062

$407.00

Racking kit Racking Hardware Kit — 20-panel System

$1,596.43

PV wire Omni Cable 8 AWG RHW-2 PV Wire Red 2000V

$1,220.00

Secure Payment Methods

Available to Order

Order today — we confirm lead time at checkout

Volume Pricing

Call 888-876-0007 for a pallet-quote

Flat Rate Shipping - Calculated at Checkout

Delivery timeframe shown above at checkout

Lifetime Customer Support

Unlimited lifetime support, always available.

Request a Free Quote

Got Questions? We’re Here to Help!

Our support team is ready to assist you with product guidance, order details, or any questions you might have.

(888) 876-0007

Instant Live Chat

Mon-Fri 10am-6pm EST

View full details

Pattern New Energy 205 $180.00

What is your return policy?

Returns are accepted within 30 days of delivery and require an RMA number. Returns of non-defective items carry a 40% restocking fee per our Refund Policy; defective, damaged-in-transit, or mis-shipped items are exempt. Special-order items are final sale.

What’s covered by your return policy?

Our returns policy covers all purchases made through Portlandia Electric Supply. For warranty issues, as authorized distributors, we honor the full manufacturer warranty of ALL the brands on our website. See our complete returns and warranty policies on our Shipping, Deliver, and Returns page.

How long will it take to receive my order?

All orders are processed within 72 hours and you can expect delivery on most orders within 5-7 business days. You will receive access to our customer portal after ordering, where it is easy to track all your shipments. See our Shipping, Delivery and Returns page for more details.

What are your financing and payment options?

We offer several ways to pay to make getting your solar kit simple:

Credit Card: if the purchase is greater than your card’s limit, you can split the cost onto multiple cards as well as Paypal, financing through Affirm, and ACH/bank transfer

You can arrange financing during the checkout process, or scroll further down this page for more details. Please note, if you'd like to finance your order, you can do so instantly, right at checkout.

How does your Lifetime Customer Support work?

Our legendary lifetime customer support has helped make us the #1 online solar retailer! We have a dedicated team of solar professionals standing by to help you navigate the world of solar with ease. From selecting the perfect solar kit to installation and beyond, we provide support and expertise at every step of the journey.If you need help with ordering, shipping, troubleshooting, expanding your system, warranty issues, or anything else you have questions about for as long as you own your Portlandia Electric Supply equipment, we’ve got you covered: we’re always only a phone call or email away.

Guangdong Pattern New Energy 205 Monocrystalline Standard Solar Panel

Model 205 | Monocrystalline Silicon | 40 Full Cells 158.75×158.75 mm | Monofacial | 1500V System Voltage

205 Wp

Max Power Output

18.16%

Module Efficiency

40 Cells

Monocrystalline

Product Overview

The Pattern New Energy 205 monocrystalline solar panel is designed for reliable power generation in compact spaces. With a rated output of 205 Wp and panel efficiency up to 18.16 percent, this module supports small residential, commercial, and off‑grid systems. Its 40 high quality monocrystalline cells convert sunlight into stable DC power, even under everyday operating temperatures around 45 degrees. A tempered glass front and anodized aluminium frame provide robust mechanical strength for long term rooftop or ground installations. The panel offers a generous power tolerance from 0 to plus 1.5 percent, so actual output can exceed the nameplate rating in real conditions. Thanks to a maximum system voltage of 1500 volts and an IP67 junction box, it integrates smoothly into modern string arrays. Manufactured by Guangdong Pattern New Energy Co., Ltd. in China, this module delivers dependable performance for a wide range of energy projects.

Key Benefits

Compact high power design: The 205 Wp rating in a 1660 by 680 millimeter frame offers strong output where space is limited, ideal for small roofs, cabins, and mobile power projects.

Reliable monocrystalline efficiency: Monocrystalline cells deliver up to 18.16 percent efficiency, helping systems produce more energy per square meter and improve overall array performance.

Stable performance in real conditions: Optimized temperature coefficients limit power loss as cell temperature rises, supporting dependable production in hot climates and strong sun.

Durable construction for long service life: A 3.2 millimeter tempered glass front, anodized aluminium frame, and IP67 junction box help protect against moisture, dust, and mechanical stress over many years.

Easy integration into modern arrays: With MC4 connectors, 900 millimeter cables, and a 1500 volt maximum system voltage, the module connects easily to contemporary inverters and balance‑of‑system components.

How It Works

This solar panel converts sunlight into usable electrical power through its monocrystalline silicon cells. Each of the forty cells absorbs photons from the sun and releases electrons, creating direct current flow. Under standard test conditions, the module delivers a maximum power of 205 watts at 22.24 volts and 9.23 amps. The panel also supports a secondary operating point, producing 152.99 watts at 20.8 volts and 7.45 amps. These operating points allow system designers to match string length and inverter input for efficient energy harvest. Protective encapsulation, tempered glass, and an anodized aluminium frame maintain structural integrity in outdoor environments. An IP67 junction box and MC4 connectors safely route the generated DC power to downstream equipment such as charge controllers or grid inverters. When installed within a 1500 volt DC array, multiple modules can be connected in series and parallel to reach the desired system size.

Monocrystalline cell energy conversion: Sunlight strikes the monocrystalline silicon cells and excites electrons inside the semiconductor material. This process creates direct current, which flows through the conductors and busbars to the panel’s output leads.

Optimized operating voltage and current: At the maximum power point, the module balances voltage and current for the highest wattage. The 22.24 volt and 9.23 amp operating point is ideal for string systems, while the alternate 20.8 volt and 7.45 amp rating supports flexible array design.

Safe power delivery through junction box and connectors: The rear junction box houses protected electrical connections and is sealed to IP67 rating. Pre‑assembled MC4 compatible connectors and 900 millimeter cables enable quick, secure linking of multiple panels without specialized tools.

Technical Specifications

Brand	Guangdong Pattern New Energy Co., Ltd.
Model Number	205
Cell Technology	Monocrystalline silicon
Cell Size	158.75 × 158.75 mm
Number of Cells	40 cells
Power Range	205 – 225 Wp
Nominal Maximum Power (Pmax)	205 Wp
Power Tolerance	0 ~ +1.5 %
Panel Efficiency Range	18.16 – 19.93 %
Module Efficiency (205 Wp)	18.16 %
Voltage at Maximum Power (Vmpp) – 205 Wp point	22.24 V
Current at Maximum Power (Impp) – 205 Wp point	9.23 A
Open Circuit Voltage (Voc) – 205 Wp point	26.56 V
Short Circuit Current (Isc) – 205 Wp point	9.78 A
Secondary Maximum Power (Pmax)	152.99 Wp
Voltage at Maximum Power (Vmpp) – 152.99 Wp point	20.8 V
Current at Maximum Power (Impp) – 152.99 Wp point	7.45 A
Open Circuit Voltage (Voc) – 152.99 Wp point	24.75 V
Short Circuit Current (Isc) – 152.99 Wp point	7.83 A
Typical Operating Temperature	45 ± 2 °C
Operating Temperature Range	-45 to +85 °C
Temperature Coefficient of Pmax	-0.396 % / °C
Temperature Coefficient of Voc	-0.31 % / °C
Temperature Coefficient of Isc	+0.06 % / °C
Maximum System Voltage (DC)	1500 V
Series Fuse Rating	15 A
Panel Dimensions (H × W × D)	1660 × 680 × 30 mm
Panel Weight	11.7 kg
Front Glass Type	Tempered glass
Front Glass Thickness	3.2 mm
Frame Material	Anodized aluminium
Junction Box Protection Class	IP67
Connector Type	MC4 compatible
Cable Length	900 mm
Country of Origin	China

Certifications & Compliance

Certifications: Manufacturer certifications not specified in the available data. Please contact us for the latest conformity details.
Inverter Compatibility: Suitable for most modern string and hybrid inverters within 1500 V DC system limits. Check exact inverter input requirements before final design.
Environmental: Designed for outdoor photovoltaic use with IP67 junction box protection and wide operating temperature range from -45 to +85 °C.
Warranty: Warranty terms are not listed in the provided specifications. Warranty information is available on request from Guangdong Pattern New Energy or your distributor.

Documentation

Product datasheet is available from the manufacturer or on request.

● Available | Contact us for lead time and pricing

What is your return policy?

What’s covered by your return policy?

How long will it take to receive my order?

What are your financing and payment options?

We offer several ways to pay to make getting your solar kit simple:

Credit Card: if the purchase is greater than your card’s limit, you can split the cost onto multiple cards as well as Paypal, financing through Affirm, and ACH/bank transfer

You can arrange financing during the checkout process, or scroll further down this page for more details. Please note, if you'd like to finance your order, you can do so instantly, right at checkout.

How does your Lifetime Customer Support work?

Guangdong Pattern New Energy 205 Monocrystalline Standard Solar Panel

Model 205 | Monocrystalline Silicon | 40 Full Cells 158.75×158.75 mm | Monofacial | 1500V System Voltage

205 Wp

Max Power Output

18.16%

Module Efficiency

40 Cells

Monocrystalline

Product Overview

Key Benefits

Compact high power design: The 205 Wp rating in a 1660 by 680 millimeter frame offers strong output where space is limited, ideal for small roofs, cabins, and mobile power projects.

Reliable monocrystalline efficiency: Monocrystalline cells deliver up to 18.16 percent efficiency, helping systems produce more energy per square meter and improve overall array performance.

Stable performance in real conditions: Optimized temperature coefficients limit power loss as cell temperature rises, supporting dependable production in hot climates and strong sun.

How It Works

Technical Specifications

Brand	Guangdong Pattern New Energy Co., Ltd.
Model Number	205
Cell Technology	Monocrystalline silicon
Cell Size	158.75 × 158.75 mm
Number of Cells	40 cells
Power Range	205 – 225 Wp
Nominal Maximum Power (Pmax)	205 Wp
Power Tolerance	0 ~ +1.5 %
Panel Efficiency Range	18.16 – 19.93 %
Module Efficiency (205 Wp)	18.16 %
Voltage at Maximum Power (Vmpp) – 205 Wp point	22.24 V
Current at Maximum Power (Impp) – 205 Wp point	9.23 A
Open Circuit Voltage (Voc) – 205 Wp point	26.56 V
Short Circuit Current (Isc) – 205 Wp point	9.78 A
Secondary Maximum Power (Pmax)	152.99 Wp
Voltage at Maximum Power (Vmpp) – 152.99 Wp point	20.8 V
Current at Maximum Power (Impp) – 152.99 Wp point	7.45 A
Open Circuit Voltage (Voc) – 152.99 Wp point	24.75 V
Short Circuit Current (Isc) – 152.99 Wp point	7.83 A
Typical Operating Temperature	45 ± 2 °C
Operating Temperature Range	-45 to +85 °C
Temperature Coefficient of Pmax	-0.396 % / °C
Temperature Coefficient of Voc	-0.31 % / °C
Temperature Coefficient of Isc	+0.06 % / °C
Maximum System Voltage (DC)	1500 V
Series Fuse Rating	15 A
Panel Dimensions (H × W × D)	1660 × 680 × 30 mm
Panel Weight	11.7 kg
Front Glass Type	Tempered glass
Front Glass Thickness	3.2 mm
Frame Material	Anodized aluminium
Junction Box Protection Class	IP67
Connector Type	MC4 compatible
Cable Length	900 mm
Country of Origin	China

Certifications & Compliance

Documentation

Product datasheet is available from the manufacturer or on request.

● Available | Contact us for lead time and pricing
