• Two black solar panels on a white background
1 1

In Stock

Phono Solar 550W Solar Panel 144 Cells Bifacial PS550M8H-24/TH Wholesale 31 panels per pallet

Phono Solar 550W Solar Panel 144 Cells Bifacial PS550M8H-24/TH Wholesale 31 panels per pallet

$197.30 USD
$197.30 USD
Sale Sold out
Shipping calculated at checkout.
Return policy

Specification

  • SKU:PES-SPS-SPL-0211
  • Documents:

    Datasheet

    Warranty
  • Height: 1.38
  • Length: 89.69
  • Width: 44.65
View full details

Product Description

  • The Phono Solar PS550M8H‑24/TH (TwinPlus Series) is a 550 W bifacial monocrystalline PERC module using 144 half-cut cells in a silver frame. Designed for high efficiency and durability across commercial, residential, and utility installations.

    • Rated Power: 550 W • Module Efficiency: ~21.29%
    • Electrical (STC): Voc ≈ 50.2 V • Vmpp ≈ 41.55 V • Impp ≈ 13.24 A • Isc ≈ 13.82 A • Tolerance: 0 ~ +3%
    • Max System Voltage: 1500 V DC • Series Fuse: 30 A
    • Operating Temp Range: −40 °F to +185 °F (−40 °C to +85 °C) • Temp Coeff (Pmax): −0.35%/°C
    • Mechanical Load Rating: 5400 Pa (snow/front); 2400 Pa (wind/rear)
    • Bifacial Gain: ~80% bifaciality factor; up to ~30% increased rear-side yield
    • Durability: PID-resistant; salt/acid/ammonia resistant
    • Connector: IP68-rated MC4 • Frame: silver anodized aluminum
    • Warranty: 12‑year product warranty; 25‑year linear power warranty (retains ≥84.8% after 25 years)
    • Packing: 31 panels per pallet • container truckload = 620 panels (if ordered at full container volume)
