    Shinson Technology S265N36BPV

    Shinson Technology S265N36BPV

    $5.00 USD
    $5.00 USD
    Sale Sold out
    Shipping calculated at checkout.
    Return policy

    Specification

    • SKU:PES-SPS-SOL-17198
    • Container price: $145.80 USD
    • Container qty: 720
    • Pallet price: $6.89 USD
    • Pallet qty: 30
    • Unit price: $0.27 USD
    View full details

    Product Description

    • Type Monocrystalline Model No. S265N36BPV Product Warranty 30 Years Power Tolerance 0 ~ +2 % Maximum Power (Pmax) 265 Wp Voltage at Maximum Power (Vmpp) 22.07 V Current at Maximum Power (Impp) 12.01 A Open Circuit Voltage (Voc) 25.24 V Short Circuit Current (Isc) 12.81 A Maximum Power (Pmax) 188 Wp Voltage at Maximum Power (Vmpp) 20.6 V Current at Maximum Power (Impp) 9.11 A Open Circuit Voltage (Voc) 24.1 V Short Circuit Current (Isc) 9.84 A Temperature 45±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.290 %/°C Temperature Coefficient of Voc -0.250 %/°C Temperature Coefficient of Isc 0.045 %/°C Maximum System Voltage 1500 V Series Fuse Rating 25 A Panel Dimension (H/W/D) 1750x1150x7.1 mm Weight 30 kg Cell Number 72 Glass Type Tempered Glass Thickness 3.2 mm Frame Type Frameless Junction Box Protection Class IP 68 Cable Crossection 4 mm2 Download Manufacturer's PDF Datasheet

      Technology: Bifacial, TOPCon, BIPV, N-type
      Power Range: 30 kg
      Panel Efficiency: 265 ~ 280 Wp
      Seller Name: Shinson Technology Co., Ltd.
      Country: China
