Shinson Technology S355M10C
PayPal Pay in 4 interest-free payments of $31.00 on qualifying orders, or monthly financing with PayPal Pay Later.
Available at checkout for eligible US buyers. Subject to approval.
Ships by freight. Carrier checkout rates can’t price this correctly — we quote the exact delivered rate to your ZIP.
Orders ship via freight or ground from our Louisville, KY warehouse. Tracking provided once your order ships.
Ships via LTL freight — palletized, liftgate available. Our team confirms freight details within 1 business day.
Secure checkout · Wire/ACH accepted on quotes · Freight arranged for you
Transit estimates from Louisville, KY. Freight details →
- SKU
- PES-SPS-SOL-17211
Complete the job
Compatible gear contractors pair with this item
PES Supply is an authorized distributor for PES Global. 50,000+ SKUs from 169 authorized brands.
Type Monocrystalline Model No. S355M10C Product Warranty 25 Years Power Tolerance 0 ~ +1.5 % Maximum Power (Pmax) 355 Wp Voltage at Maximum Power (Vmpp) 33.37 V Current at Maximum Power (Impp) 10.64 A Open Circuit Voltage (Voc) 38.68 V Short Circuit Current (Isc) 11.49 A Panel Efficiency 18.2 % Maximum Power (Pmax) 267 Wp Voltage at Maximum Power (Vmpp) 31.41 V Current at Maximum Power (Impp) 8.52 A Open Circuit Voltage (Voc) 36.72 V Short Circuit Current (Isc) 9.4 A Temperature 45±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.29 %/°C Temperature Coefficient of Voc -0.25 %/°C Temperature Coefficient of Isc 0.045 %/°C Maximum System Voltage 1500 V Series Fuse Rating 25 A Panel Dimension (H/W/D) 1722x1134x30 mm Weight 20.5 kg Cell Number 108 Glass Type Anti-reflection Coating, Tempered Glass Thickness 3.2 mm Frame Type Anodized Aluminium Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Cable Length 1200 mm Download Manufact
Technology: TOPCon
Power Range: 350 ~ 365 Wp
Panel Efficiency: 17.9 ~ 18.7 %
Weight: 20.5 kg
Seller Name: Shinson Technology Co., Ltd.
Country: China
| SKU | PES-SPS-SOL-17211 |
|---|---|
| Manufacturer | PES Global |
| Container price | |
| Container qty | |
| Odoo id | |
| Pallet price | |
| Pallet qty | |
| Unit price | |
| Manufacturer | |
| Model number |
No documents available for this product. Contact us to request documentation.
