    Shinson Technology S435M54NF3BFB

    Shinson Technology S435M54NF3BFB

    $5.00 USD
    $5.00 USD
    Sale Sold out
    Shipping calculated at checkout.
    Return policy

    Specification

    • SKU:PES-SPS-SOL-17241
    • Container price: $43.20 USD
    • Container qty: 720
    • Odoo id: 24,444
    • Pallet price: $2.04 USD
    • Pallet qty: 30
    • Unit price: $0.08 USD
    View full details

    Product Description

    • Type Monocrystalline Model No. S435M54NF3BFB Product Warranty 30 Years Maximum Power (Pmax) 435 Wp Voltage at Maximum Power (Vmpp) 32.85 V Current at Maximum Power (Impp) 13.33 A Open Circuit Voltage (Voc) 39.6 V Short Circuit Current (Isc) 13.76 A Panel Efficiency 21.77 % Temperature 42±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.310 %/°C Temperature Coefficient of Voc -0.260 %/°C Temperature Coefficient of Isc +0.046 %/°C Maximum System Voltage 1500 V Series Fuse Rating 25 A Panel Dimension (H/W/D) 1762x1134x28 mm Weight 20.5 kg Cell Number 108 Glass Thickness 1.6 mm Encapsulant Type EVA Junction Box Diodes 3 Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Cable Length 1100 mm Download Manufacturer's PDF Datasheet

      Technology: TOPCon
      Power Range: 435 ~ 450 Wp
      Panel Efficiency: 21.77 ~ 22.52 %
      Weight: 20.5 kg
      Seller Name: Shinson Technology Co., Ltd.
      Country: China
