Shinson Technology S705M66HT4BF
PayPal Pay in 4 interest-free payments of $61.75 on qualifying orders, or monthly financing with PayPal Pay Later.
Available at checkout for eligible US buyers. Subject to approval.
Ships by freight. Carrier checkout rates can’t price this correctly — we quote the exact delivered rate to your ZIP.
Orders ship via freight or ground from our Louisville, KY warehouse. Tracking provided once your order ships.
Ships via LTL freight — palletized, liftgate available. Our team confirms freight details within 1 business day.
Secure checkout · Wire/ACH accepted on quotes · Freight arranged for you
Transit estimates from Louisville, KY. Freight details →
- SKU
- PES-SPS-SOL-17287
Complete the job
Compatible gear contractors pair with this item
PES Supply is an authorized distributor for PES Global. 50,000+ SKUs from 169 authorized brands.
Type Monocrystalline Model No. S705M66HT4BF Product Warranty 30 Years Maximum Power (Pmax) 705 Wp Voltage at Maximum Power (Vmpp) 42.25 V Current at Maximum Power (Impp) 16.69 A Open Circuit Voltage (Voc) 50.29 V Short Circuit Current (Isc) 17.49 A Panel Efficiency 22.7 % Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.26 %/°C Temperature Coefficient of Voc -0.24 %/°C Temperature Coefficient of Isc +0.04 %/°C Maximum System Voltage 1500 V Series Fuse Rating 30 A Panel Dimension (H/W/D) 2384x1303x35 mm Weight 38.7 kg Cell Number 132 Glass Type Anti-reflection Coating, Tempered Glass Thickness 2 mm Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Download Manufacturer's PDF Datasheet
Technology: HJT
Power Range: 700 ~ 720 Wp
Panel Efficiency: 22.53 ~ 23.18 %
Weight: 38.7 kg
Seller Name: Shinson Technology Co., Ltd.
Country: China
| SKU | PES-SPS-SOL-17287 |
|---|---|
| Manufacturer | PES Global |
| Container price | |
| Container qty | |
| Odoo id | |
| Pallet price | |
| Pallet qty | |
| Unit price | |
| Manufacturer |
No documents available for this product. Contact us to request documentation.
