    Solar N Plus 565

    Solar N Plus 565

    $5.00 USD
    $5.00 USD
    Sale Sold out
    Shipping calculated at checkout.
    Return policy

    Specification

    • SKU:PES-SPS-SOL-17690
    • Container price: $48.60 USD
    • Container qty: 720
    • Odoo id: 24,659
    • Pallet price: $2.29 USD
    • Pallet qty: 30
    • Unit price: $0.09 USD
    View full details

    Product Description

    • Type Monocrystalline Model No. 565 Product Warranty 15 Years Power Warranty 30 Years of 87.4 % Total Degradation Rate ⏳ 0.42 % Power Tolerance 0 ~ +0.5 % Maximum Power (Pmax) 565 Wp Voltage at Maximum Power (Vmpp) 44.55 V Current at Maximum Power (Impp) 12.68 A Open Circuit Voltage (Voc) 52 V Short Circuit Current (Isc) 13.42 A Panel Efficiency 21.9 % Maximum Power (Pmax) 433 Wp Voltage at Maximum Power (Vmpp) 41.36 V Current at Maximum Power (Impp) 10.47 A Open Circuit Voltage (Voc) 49.53 V Short Circuit Current (Isc) 10.86 A Temperature 42±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.29 %/°C Temperature Coefficient of Voc -0.25 %/°C Temperature Coefficient of Isc 0.045 %/°C Maximum System Voltage 1500 V Series Fuse Rating 25 A Panel Dimension (H/W/D) 2278x1134x30 mm Weight 32.5 kg Cell Number 144 Glass Type Anti-reflection Coating Glass Thickness 2 mm Frame Type Black Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Ca

      Technology: Bifacial, N-type
      Power Range: 560 ~ 590 Wp
      Panel Efficiency: 21.7 ~ 22.8 %
      Weight: 32.5 kg
      Seller Name: Solar N Plus New Energy Tech. Co., Ltd
      Country: China
