Out of Stock
Solar N Plus 705
Solar N Plus 705
Couldn't load pickup availability
Specification
- SKU:PES-SPS-SOL-17709
- Container price:
- Container qty:
- Pallet price:
- Pallet qty:
- Unit price:
Product Description
-
Type Monocrystalline Model No. 705 Product Warranty 15 Years Power Warranty 30 Years of 87.4 % Total Degradation Rate ⏳ 0.42 % Power Tolerance 0 ~ +0.5 % Maximum Power (Pmax) 705 Wp Voltage at Maximum Power (Vmpp) 40.7 V Current at Maximum Power (Impp) 17.32 A Open Circuit Voltage (Voc) 48.5 V Short Circuit Current (Isc) 18.36 A Panel Efficiency 22.7 % Maximum Power (Pmax) 538 Wp Voltage at Maximum Power (Vmpp) 38.2 V Current at Maximum Power (Impp) 14.08 A Open Circuit Voltage (Voc) 46.2 V Short Circuit Current (Isc) 14.8 A Temperature 43±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.3 %/°C Temperature Coefficient of Voc -0.24 %/°C Temperature Coefficient of Isc 0.04 %/°C Maximum System Voltage 1500 V Series Fuse Rating 35 A Panel Dimension (H/W/D) 2384x1303x33 mm Weight 38.1 kg Cell Number 132 Glass Type Anti-reflection Coating Glass Thickness 2 mm Frame Type Anodized Aluminium Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection
Technology: Bifacial, N-type
Power Range: 700 ~ 720 Wp
Panel Efficiency: 22.5 ~ 23.2 %
Weight: 38.1 kg
Seller Name: Solar N Plus New Energy Tech. Co., Ltd
Country: China -
