SolarEdge RGM 3.0kW 3-Ph Inverter - SE3000A-US000NNR2

SolarEdge RGM 3.0kW 3-Ph Inverter - SE3000A-US000NNR2

Call Now Email Us
Return policy

Specification

  • SKU:PES-SPS-SIV-0088
  • Brands: SolarEdge
  • Compliance special features:
    • Rapid Shutdown Ready
    • NEMA 3R
  • Documents:

    Datasheet
  • Height: 30.5
  • Length: 7.2
  • Special sections quote cta:
    • AFCI
View full details

  • Product Description

    SolarEdge RGM 3.0kW 3-Phase Inverter - SE3000A-US000NNR2

    The SolarEdge SE3000A-US000NNR2 inverter is designed for optimized solar systems, ensuring superior efficiency and reliable performance. It integrates seamlessly with power optimizers, providing maximum solar power conversion and management. With built-in features like arc fault protection and rapid shutdown, this inverter meets North American safety standards, making it an ideal choice for residential solar installations.

    Product Features

    Superior Energy Conversion

    The SolarEdge SE3000A-US inverter offers remarkable efficiency of up to 98%, enabling substantial energy capture and conversion, optimizing your solar array's performance with the target keyword.

    Integrated Safety Protocols

    This inverter includes built-in arc fault detection and rapid shutdown capabilities, ensuring adherence to the latest NEC safety requirements for residential installations.

    Modular Monitoring Capabilities

    With integrated module-level monitoring, users can track energy production and system performance through both Ethernet and wireless connectivity, promoting user engagement and system transparency.

    Compact and Lightweight Design

    A small, lightweight build facilitates easy installation both indoors and outdoors, simplifying setup and reducing associated labor costs for installers.

    Versatile Communication Options

    Equipped with RS485, RS232, and optional ZigBee communication interfaces, users can select the most suitable method for data transmission and system monitoring.

    How It Works

    The SolarEdge SE3000A-US000NNR2 operates by converting direct current (DC) electricity generated by solar panels into alternating current (AC) electricity used by home appliances, employing power optimizers for enhanced performance while maintaining fixed voltage for extended strings.

    DC to AC Conversion

    The inverter efficiently transforms energy from your solar panels, ensuring seamless integration with your household electrical system and maximizing energy production.

    Power Optimizer Integration

    Working alongside SolarEdge power optimizers, this inverter increases overall system efficiency by reducing power losses and optimizing energy management at the module level.

    Safety and Rapid Shutdown

    Featuring automated rapid shutdown upon AC grid disconnect, it complies with NEC regulations, enhancing safety during emergency situations or maintenance.

    Specifications

    Nominal AC Power Output 3000 VA
    Max. AC Power Output 3300 VA
    AC Output Voltage 183 - 229 Vac
    AC Frequency 59.3 - 60.5 Hz
    Max. Continuous Output Current 12.5 A
    Maximum DC Power (STC) 4050 W
    Max. Input Voltage 500 Vdc
    Max. Input Current 9.5 Adc
    Maximum Inverter Efficiency 98 %
    Nighttime Power Consumption < 2.5 W
    Dimensions (HxWxD) 30.5 x 12.5 x 10.5 in
    Weight 51.2 lb / 23.2 kg
    Operating Temperature Range -13 to +140 ËšF / -25 to +60 ËšC
    Protection Rating NEMA 3R
