SpolarPV SP355BSM6-72
SpolarPV SP355BSM6-72
Couldn't load pickup availability
Specification
- SKU:PES-SPS-SOL-18510
- Container price:
- Container qty:
- Odoo id:
- Pallet price:
- Pallet qty:
- Unit price:
Product Description
-
Type Monocrystalline Model No. SP355BSM6-72 Product Warranty 12 Years Power Warranty 12 Years of 90 %, 30 Years of 80 % Total Degradation Rate ⏳ 0.67 % Power Tolerance 0 ~ +1.5 % Maximum Power (Pmax) 355 Wp Voltage at Maximum Power (Vmpp) 39.66 V Current at Maximum Power (Impp) 8.95 A Open Circuit Voltage (Voc) 46.82 V Short Circuit Current (Isc) 9.72 A Panel Efficiency 18.3 % Maximum Power (Pmax) 268 Wp Voltage at Maximum Power (Vmpp) 36.09 V Current at Maximum Power (Impp) 7.42 A Open Circuit Voltage (Voc) 43.83 V Short Circuit Current (Isc) 7.84 A Temperature 45±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.38 %/°C Temperature Coefficient of Voc -0.33 %/°C Temperature Coefficient of Isc 0.05 %/°C Maximum System Voltage 1500 V Series Fuse Rating 20 A Panel Dimension (H/W/D) 1956x992x40 mm Weight 21.5 kg Cell Size 156.75×156.75 mm Cell Number 72 Glass Type Tempered Glass Thickness 3.2 mm Frame Type Anodized Aluminium Junction Box Diodes 3 Junction Bo
Technology: Bifacial, PERC
Power Range: 355 ~ 390 Wp
Panel Efficiency: 18.3 ~ 20.1 %
Weight: 21.5 kg
Seller Name: SpolarPV Technology Co., Ltd.
Country: China -
