    SpolarPV SP380BSM6-72

    SpolarPV SP380BSM6-72

    $5.00 USD
    $5.00 USD
    Sale Sold out
    Shipping calculated at checkout.
    Return policy

    Specification

    • SKU:PES-SPS-SOL-18517
    • Container price: $54.00 USD
    • Container qty: 720
    • Odoo id: 24,321
    • Pallet price: $2.55 USD
    • Pallet qty: 30
    • Unit price: $0.10 USD
    View full details

    Product Description

    • Type Monocrystalline Model No. SP380BSM6-72 Product Warranty 12 Years Power Warranty 12 Years of 90 %, 30 Years of 80 % Total Degradation Rate ⏳ 0.67 % Power Tolerance 0 ~ +1.5 % Maximum Power (Pmax) 380 Wp Voltage at Maximum Power (Vmpp) 41.08 V Current at Maximum Power (Impp) 9.25 A Open Circuit Voltage (Voc) 48.38 V Short Circuit Current (Isc) 10.07 A Panel Efficiency 19.58 % Maximum Power (Pmax) 287 Wp Voltage at Maximum Power (Vmpp) 37.38 V Current at Maximum Power (Impp) 7.68 A Open Circuit Voltage (Voc) 44.93 V Short Circuit Current (Isc) 8.19 A Temperature 45±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.38 %/°C Temperature Coefficient of Voc -0.33 %/°C Temperature Coefficient of Isc 0.05 %/°C Maximum System Voltage 1500 V Series Fuse Rating 20 A Panel Dimension (H/W/D) 1956x992x40 mm Weight 21.5 kg Cell Size 156.75×156.75 mm Cell Number 72 Glass Type Tempered Glass Thickness 3.2 mm Frame Type Anodized Aluminium Junction Box Diodes 3 Junction

      Technology: Bifacial, PERC
      Power Range: 355 ~ 390 Wp
      Panel Efficiency: 18.3 ~ 20.1 %
      Weight: 21.5 kg
      Seller Name: SpolarPV Technology Co., Ltd.
      Country: China
