    SunEvo Solar EVO5N SE5-72HBD 570W

    SunEvo Solar EVO5N SE5-72HBD 570W

    $5.00 USD
    $5.00 USD
    Sale Sold out
    Shipping calculated at checkout.
    Return policy

    Specification

    • SKU:PES-SPS-SOL-18781
    • Container price: $43.20 USD
    • Container qty: 720
    • Odoo id: 24,909
    • Pallet price: $2.04 USD
    • Pallet qty: 30
    • Unit price: $0.08 USD
    View full details

    Product Description

    • Type Monocrystalline Model No. EVO5N SE5-72HBD 570W Product Warranty 30 Years Power Warranty 10 Years of 90 %, 25 Years of 84.7 % Total Degradation Rate ⏳ 0.61 % Power Tolerance 0 ~ +0.9 % Maximum Power (Pmax) 570 Wp Voltage at Maximum Power (Vmpp) 43.58 V Current at Maximum Power (Impp) 13.08 A Open Circuit Voltage (Voc) 52.1 V Short Circuit Current (Isc) 13.83 A Panel Efficiency 22.07 % Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.30 %/°C Temperature Coefficient of Voc -0.25 %/°C Temperature Coefficient of Isc +0.046 %/°C Maximum System Voltage 1500 V Series Fuse Rating 30 A Panel Dimension (H/W/D) 2279x1134x35 mm Weight 27.5 kg Cell Size 182×182 mm Cell Number 144 Glass Type Tempered Glass Thickness 3.2 mm Encapsulant Type EVA Back Cover Type TPT Frame Type Anodized Aluminium Junction Box Diodes 3 Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Cable Length 300 mm Download Manufacturer's PDF Datasheet

      Technology: Bifacial, TOPCon
      Power Range: 565 ~ 585 Wp
      Panel Efficiency: 21.86 ~ 22.65 %
      Weight: 27.5 kg
      Seller Name: SunEvo Solar Co., Ltd.
      Country: China
