SunEvo Solar SE5 310M
SunEvo Solar SE5 310M
Couldn't load pickup availability
Specification
- SKU:PES-SPS-SOL-18793
- Container price:
- Container qty:
- Odoo id:
- Pallet price:
- Pallet qty:
- Unit price:
Product Description
-
Type Monocrystalline Model No. SE5 310M Product Warranty 25 Years Power Tolerance 0 ~ +2.54 % Maximum Power (Pmax) 310 Wp Voltage at Maximum Power (Vmpp) 34.51 V Current at Maximum Power (Impp) 8.72 A Open Circuit Voltage (Voc) 41.61 V Short Circuit Current (Isc) 9.19 A Panel Efficiency 21.35 % Temperature 45±2 °C Operating Temperature Range -40 - +85 °C Temperature Coefficient of Pmax -0.350 %/°C Temperature Coefficient of Voc -0.270 %/°C Temperature Coefficient of Isc 0.048 %/°C Maximum System Voltage 700 V Series Fuse Rating 15 A Cell Size 182×182 mm Cell Number 64 Glass Type Tempered Glass Thickness 3.2 mm Frame Type Anodized Aluminium Junction Box Diodes 3 Junction Box Protection Class IP 67 Connector Type MC4 Cable Crossection 4 mm2 Cable Length 900 mm Download Manufacturer's PDF Datasheet
Power Range: 100 ~ 310 Wp
Panel Efficiency: 18.16 ~ 21.35 %
Seller Name: SunEvo Solar Co., Ltd.
Country: China -
