    SunEvo Solar SE5-40HBD 335W

    SunEvo Solar SE5-40HBD 335W

    $5.00 USD
    $5.00 USD
    Sale Sold out
    Shipping calculated at checkout.
    Return policy

    Specification

    • SKU:PES-SPS-SOL-18797
    • Container price: $48.60 USD
    • Container qty: 720
    • Odoo id: 24,180
    • Pallet price: $2.29 USD
    • Pallet qty: 30
    • Unit price: $0.09 USD
    View full details

    Product Description

    • Type Monocrystalline Model No. SE5-40HBD 335W Product Warranty 25 Years Power Warranty 30 Years of 87.4 % Total Degradation Rate ⏳ 0.42 % Power Tolerance 0 ~ +1.52 % Maximum Power (Pmax) 335 Wp Voltage at Maximum Power (Vmpp) 25.2 V Current at Maximum Power (Impp) 13.29 A Open Circuit Voltage (Voc) 28.58 V Short Circuit Current (Isc) 14.16 A Panel Efficiency 14.2 % Temperature 42±3 °C Operating Temperature Range -40 - +85 °C Temperature Coefficient of Pmax -0.30 %/°C Temperature Coefficient of Voc -0.25 %/°C Temperature Coefficient of Isc +0.04 %/°C Maximum System Voltage 1500 V Series Fuse Rating 25 A Panel Dimension (H/W/D) 2088x1128x5 mm Weight 27 kg Cell Number 80 Glass Type Tempered Glass Thickness 2 mm Encapsulant Type EVA Frame Type Frameless Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Download Manufacturer's PDF Datasheet

      Technology: Bifacial
      Power Range: 320 ~ 340 Wp
      Panel Efficiency: 13.6 ~ 14.4 %
      Weight: 27 kg
      Seller Name: SunEvo Solar Co., Ltd.
      Country: China
