SunEvo Solar SE5-54H 435W

SunEvo Solar SE5-54H 435W

$5.00 USD
$5.00 USD
Sale Sold out
Shipping calculated at checkout.
Return policy

Specification

  • SKU:PES-SPS-SOL-18802
  • Container price: $54.00 USD
  • Container qty: 720
  • Pallet price: $2.55 USD
  • Pallet qty: 30
  • Unit price: $0.10 USD
View full details

Product Description

  • Type Monocrystalline Model No. SE5-54H 435W Product Warranty 25 Years Power Warranty 30 Years of 88 % Total Degradation Rate ⏳ 0.4 % Power Tolerance 0 ~ +1 % Maximum Power (Pmax) 435 Wp Voltage at Maximum Power (Vmpp) 34.86 V Current at Maximum Power (Impp) 12.48 A Open Circuit Voltage (Voc) 41.64 V Short Circuit Current (Isc) 13 A Panel Efficiency 22.28 % Maximum Power (Pmax) 331 Wp Voltage at Maximum Power (Vmpp) 32.91 V Current at Maximum Power (Impp) 10.06 A Open Circuit Voltage (Voc) 39.74 V Short Circuit Current (Isc) 10.48 A Temperature 44±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.26 %/°C Temperature Coefficient of Voc -0.24 %/°C Temperature Coefficient of Isc +0.04 %/°C Maximum System Voltage 1500 V Series Fuse Rating 25 A Panel Dimension (H/W/D) 1722x1134x35 mm Weight 21 kg Cell Number 108 Glass Thickness 3.2 mm Frame Type Anodized Aluminium Junction Box Diodes 3 Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Cable Length 300 mm Download Manufacturer's PDF Datasheet

    Technology: HJT
    Power Range: 430 ~ 450 Wp
    Panel Efficiency: 22.02 ~ 23.04 %
    Weight: 21 kg
    Seller: SunEvo Solar Co., Ltd.
    Country: China
