    SunEvo Solar SE5-54HBC 420W

    SunEvo Solar SE5-54HBC 420W

    $5.00 USD
    $5.00 USD
    Sale Sold out
    Shipping calculated at checkout.
    Return policy

    Specification

    • SKU:PES-SPS-SOL-18806
    • Container price: $54.00 USD
    • Container qty: 720
    • Odoo id: 24,715
    • Pallet price: $2.55 USD
    • Pallet qty: 30
    • Unit price: $0.10 USD
    View full details

    Product Description

    • Type Monocrystalline Model No. SE5-54HBC 420W Product Warranty 15 Years Power Warranty 25 Years of 88.90 % Total Degradation Rate ⏳ 0.44 % Power Tolerance 0 ~ +1 % Maximum Power (Pmax) 420 Wp Voltage at Maximum Power (Vmpp) 32.44 V Current at Maximum Power (Impp) 12.95 A Open Circuit Voltage (Voc) 38.73 V Short Circuit Current (Isc) 14 A Panel Efficiency 21.5 % Maximum Power (Pmax) 314 Wp Voltage at Maximum Power (Vmpp) 29.6 V Current at Maximum Power (Impp) 10.6 A Open Circuit Voltage (Voc) 36.36 V Short Circuit Current (Isc) 11.31 A Temperature 45±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.29 %/°C Temperature Coefficient of Voc -0.23 %/°C Temperature Coefficient of Isc +0.050 %/°C Maximum System Voltage 1500 V Series Fuse Rating 25 A Panel Dimension (H/W/D) 1722x1134x30 mm Weight 20.8 kg Cell Number 108 Glass Type Tempered Glass Thickness 3.2 mm Frame Type Anodized Aluminium Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection

      Technology: Back Contact
      Power Range: 420 ~ 455 Wp
      Panel Efficiency: 21.5 ~ 23.3 %
      Weight: 20.8 kg
      Seller Name: SunEvo Solar Co., Ltd.
      Country: China
