SunEvo Solar SE5-54HBD 430MB
SunEvo Solar SE5-54HBD 430MB
Couldn't load pickup availability
Specification
- SKU:PES-SPS-SOL-18820
- Container price:
- Container qty:
- Pallet price:
- Pallet qty:
- Unit price:
Product Description
-
Type Monocrystalline Model No. SE5-54HBD 430MB Product Warranty 25 Years Power Warranty 30 Years of 87.40 % Total Degradation Rate ⏳ 0.42 % Power Tolerance 0 ~ +1.2 % Maximum Power (Pmax) 430 Wp Voltage at Maximum Power (Vmpp) 32.65 V Current at Maximum Power (Impp) 13.17 A Open Circuit Voltage (Voc) 39.04 V Short Circuit Current (Isc) 14.1 A Panel Efficiency 22.02 % Maximum Power (Pmax) 323 Wp Voltage at Maximum Power (Vmpp) 30.07 V Current at Maximum Power (Impp) 10.74 A Open Circuit Voltage (Voc) 37.15 V Short Circuit Current (Isc) 11.36 A Temperature 45±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.30 %/°C Temperature Coefficient of Voc -0.25 %/°C Temperature Coefficient of Isc +0.04 %/°C Maximum System Voltage 1500 V Series Fuse Rating 25 A Panel Dimension (H/W/D) 1722x1134x30 mm Weight 21 kg Cell Size 182×182 mm Cell Number 108 Glass Type Tempered Glass Thickness 3.2 mm Encapsulant Type EVA Back Cover Type TPT Frame Type Anodized Aluminium Junction Box Diodes 3 Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Cable Length 300 mm Download Manufacturer's PDF Datasheet
Technology: Bifacial, TOPCon
Power Range: 415 ~ 435 Wp
Panel Efficiency: 21.25 ~ 22.27 %
Weight: 21 kg
Seller: SunEvo Solar Co., Ltd.
Country: China -
