1 0

    In Stock

    SunEvo Solar SE6-66HBD-745M

    SunEvo Solar SE6-66HBD-745M

    $5.00 USD
    $5.00 USD
    Sale Sold out
    Shipping calculated at checkout.
    Return policy

    Specification

    • SKU:PES-SPS-SOL-18899
    • Container price: $48.60 USD
    • Container qty: 720
    • Odoo id: 25,006
    • Pallet price: $2.29 USD
    • Pallet qty: 30
    • Unit price: $0.09 USD
    View full details

    Product Description

    • Type Monocrystalline Model No. SE6-66HBD-745M Product Warranty 30 Years Power Warranty 12 Years of 95 %, 30 Years of 90.3 % Total Degradation Rate ⏳ 0.32 % Power Tolerance 0 ~ +0.8 % Maximum Power (Pmax) 745 Wp Voltage at Maximum Power (Vmpp) 42.59 V Current at Maximum Power (Impp) 17.5 A Open Circuit Voltage (Voc) 50.67 V Short Circuit Current (Isc) 18.62 A Panel Efficiency 24 % Operating Temperature Range -40 - +85 °C Temperature Coefficient of Pmax -0.3 %/°C Temperature Coefficient of Voc -0.25 %/°C Temperature Coefficient of Isc +0.046 %/°C Maximum System Voltage 1500 V Series Fuse Rating 25 A Panel Dimension (H/W/D) 2384x1303x33 mm Weight 37.9 kg Cell Size 210×210 mm Cell Number 132 Glass Thickness 2.0 mm Encapsulant Type EVA Back Cover Type TPT Frame Type Anodized Aluminium Junction Box Diodes 3 Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Cable Length 350 mm Download Manufacturer's PDF Datasheet

      Technology: HJT, N-type
      Power Range: 730 ~ 750 Wp
      Panel Efficiency: 23.5 ~ 24.1 %
      Weight: 37.9 kg
      Seller Name: SunEvo Solar Co., Ltd.
      Country: China
