Sunpro Power SPDG505-N108R12
Sunpro Power SPDG505-N108R12
Couldn't load pickup availability
Specification
- SKU:PES-SPS-SOL-19733
- Container price:
- Container qty:
- Pallet price:
- Pallet qty:
- Unit price:
Product Description
-
Type Monocrystalline Model No. SPDG505-N108R12 Product Warranty 25 Years Power Warranty 25 Years of 89.4 %, 30 Years of 87.4 % Total Degradation Rate ⏳ 0.42 % Maximum Power (Pmax) 505 Wp Voltage at Maximum Power (Vmpp) 33.6 V Current at Maximum Power (Impp) 15.03 A Open Circuit Voltage (Voc) 40.24 V Short Circuit Current (Isc) 15.88 A Panel Efficiency 22.72 % Maximum Power (Pmax) 382.2 Wp Voltage at Maximum Power (Vmpp) 31.6 V Current at Maximum Power (Impp) 12.08 A Open Circuit Voltage (Voc) 38.1 V Short Circuit Current (Isc) 12.79 A Temperature 45±2 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.3 %/°C Temperature Coefficient of Voc -0.25 %/°C Temperature Coefficient of Isc 0.045 %/°C Maximum System Voltage 1500 V Series Fuse Rating 30 A Panel Dimension (H/W/D) 1960x1134x30 mm Weight 26.6 kg Cell Size 182.2×105 mm Cell Number 108 Glass Type Anti-reflection Coating, Tempered Glass Thickness 2.0 mm Encapsulant Type EVA Frame Type Anodized Aluminium Junction Box Diodes 3 Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Cable Length 1300 mm Download Manufacturer's PDF Datasheet
Technology: Bifacial, TOPCon, N-type
Power Range: 500 ~ 515 Wp
Panel Efficiency: 22.5 ~ 23.17 %
Weight: 26.6 kg
Seller: Zhejiang Sunpro Power Technology Co., Ltd.
Country: China -
