    Topsky Energy CS6W-595TB-AG

    Topsky Energy CS6W-595TB-AG

    $5.00 USD
    $5.00 USD
    Sale Sold out
    Shipping calculated at checkout.
    Return policy

    Specification

    • SKU:PES-SPS-SOL-21191
    • Brand: Canadian Solar
    • Container price: $48.60 USD
    • Container qty: 720
    • Odoo id: 25,546
    • Pallet price: $2.29 USD
    • Pallet qty: 30
    View full details

    Product Description

    • Type Monocrystalline Model No. CS6W-595TB-AG Product Warranty 12 Years Power Tolerance 0 ~ +2 % Maximum Power (Pmax) 595 Wp Voltage at Maximum Power (Vmpp) 43.7 V Current at Maximum Power (Impp) 13.62 A Open Circuit Voltage (Voc) 52.8 V Short Circuit Current (Isc) 14.12 A Panel Efficiency 23 % Maximum Power (Pmax) 450 Wp Voltage at Maximum Power (Vmpp) 41.3 V Current at Maximum Power (Impp) 10.89 A Open Circuit Voltage (Voc) 50 V Short Circuit Current (Isc) 11.39 A Temperature 41±3 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.29 %/°C Temperature Coefficient of Voc -0.25 %/°C Temperature Coefficient of Isc 0.05 %/°C Maximum System Voltage 1500 V Series Fuse Rating 30 A Panel Dimension (H/W/D) 2278x1134x30 mm Weight 32.3 kg Cell Number 144 Glass Type Anti-reflection Coating, Tempered Glass Thickness 2 mm Frame Type Anodized Aluminium Junction Box Diodes 3 Junction Box Protection Class IP 68 Connector Type MC4 Cable Crossection 4 mm2 Cable Length 300 mm D

      Technology: Bifacial, TOPCon
      Power Range: 580 ~ 595 Wp
      Panel Efficiency: 22.5 ~ 23 %
      Weight: 32.3 kg
      Seller Name: Shenzhen Topsky Energy Co., Ltd.
      Country: China
