    Topsky Energy CS7L-635TB-AG

    Topsky Energy CS7L-635TB-AG

    $5.00 USD
    $5.00 USD
    Sale Sold out
    Shipping calculated at checkout.
    Return policy

    Specification

    • SKU:PES-SPS-SOL-21195
    • Container price: $48.60 USD
    • Container qty: 720
    • Odoo id: 25,555
    • Pallet price: $2.29 USD
    • Pallet qty: 30
    • Unit price: $0.09 USD
    View full details

    Product Description

    • Type Monocrystalline Model No. CS7L-635TB-AG Product Warranty 12 Years Power Warranty 1 Years of 99 % Total Degradation Rate ⏳ 1 % Power Tolerance 0 ~ +1.5 % Maximum Power (Pmax) 635 Wp Voltage at Maximum Power (Vmpp) 36.3 V Current at Maximum Power (Impp) 17.5 A Open Circuit Voltage (Voc) 43.5 V Short Circuit Current (Isc) 18.46 A Panel Efficiency 22.4 % Maximum Power (Pmax) 480 Wp Voltage at Maximum Power (Vmpp) 34.3 V Current at Maximum Power (Impp) 13.99 A Open Circuit Voltage (Voc) 41.2 V Short Circuit Current (Isc) 14.89 A Temperature 41±3 °C Operating Temperature Range -40 - 85 °C Temperature Coefficient of Pmax -0.29 %/°C Temperature Coefficient of Voc -0.25 %/°C Temperature Coefficient of Isc 0.05 %/°C Maximum System Voltage 1500 V Series Fuse Rating 35 A Panel Dimension (H/W/D) 2172x1303x33 mm Weight 34.5 kg Cell Number 120 Glass Type Anti-reflection Coating, Tempered Glass Thickness 2 mm Frame Type Anodized Aluminium Junction Box Diodes 3 Junction Box Protection Class IP 68

      Technology: Bifacial, TOPCon, N-type
      Power Range: 620 ~ 640 Wp
      Panel Efficiency: 21.9 ~ 22.6 %
      Weight: 34.5 kg
      Seller Name: Shenzhen Topsky Energy Co., Ltd.
      Country: China
